46
Installation and Maintenance
Service Manual
NO.
Description
Part Code
QtyLM036HO-100P232-1X
Product Code Y6706
1 Axial Flow Fan 10335005 1
2 Fan Motor 1501506203 1
3 Capacitor 3300008105 1
4 Main Board 30135844 1
5 Capacitor CBB61 33010011 1
6 AC Contactor 44010256 1
7 Transformer 43110236 1
8 Terminal Board 4201025801 1
9 Electric Box Assy 02613473 1
10 Left Side Plate 01305043P 1
11 Top Cover Sub-Assy 01255007 1
12 Motor Support Sub-Assy 01705437 1
13 Clapboard 01235063 1
14 Condenser Assy 01163742 1
15 Pressure Protect Switch 46020003 1
16 Magnet Coil 430004002 1
17 4-Way Valve Assy 03073086 1
18 Rear Grill 0147307003 1
19 Temperature Sensor 3900012121 1
20 Big Handle 26235001 1
21 Valve Support Sub-Assy 0171501201P 1
22 Cut-off Valve 0713507701 1
23 Cut off Valve 071302111 1
24 Compressor and Fittings 00103110 1
25 Chassis Sub-assy 02803193P 1
26 Drainage Connecter 06123401 1
27 Front Side Plate 01305086P 1
28 Left Handle 26235401 2
29 Cabinet 01435004P 1
30 Front Grill 22415003 1
31 Valve Cover 22245003 1
Above data is subject to change without notice.
