Lennox LM036CI-100P232-1X User Manual

56
Installation and Maintenance
Service Manual
side panel, protecting case and chassis
Unscrew the screws connect to top
ProcedureSteps
a
b
a
1. Remove top cover plate and front
s
ide panel
cover plate, panel, right ,left side
panel and
valve cover by screwdriver
to remove the top cover plate and
valve cover.
Unscrewthe screws connect front
to removethe front sidepanel.
2. Remove panel grill and panel
Unscrewthe screwsof fixingpanel grill
and panelby screwdriver to remove the
panelgrill.
panel grill
front side panel
top cover
valve cover
11.2 Removal Procedure of Outdoor Unit
NOTE:Take LM036HO-100P232-1X unit as example.
