Lennox LM036CI-100P232-1X User Manual

2
Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Model LM036CI-100P232-1X/LM036CO-100P232-1X
Product Code Y6695/Y6696
Power Supply
Rated Voltage V~ 220-230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity Btu/h 36000
Heating Capacity W /
Cooling Power Input W 3450
Heating Power Input W /
Cooling Power Current A 15.3
Heating Power Current A /
Rated Input W 4300
Rated Current A 19
Air Flow Volume(SH/H/M/L/SL) m
3
/h 1450/1350/1200/1050/-
Dehumidifying Volume L/h 3.5
EER W/W 2.8
COP W/W /
SEER /
HSPF /
Application Area m
2
46-70
Indoor Unit
Model of indoor unit LM036CI-100P232-1X
Indoor Unit Product Code Y6695
Fan Type Cross-ow
Diameter Length(DXL) mm Φ108X522.7
Fan Motor Cooling Speed (SH/H/M/L/SL) r/min 1450/1350/1200/1050/-
Fan Motor Heating Speed (SH/H/M/L/SL) r/min /
Output of Fan Motor W 60
Fan Motor RLA A 0.52
Fan Motor Capacitor μF 3
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7
Row-n Gap mm 2-1.5
Coil Length (LXDXW) mm 1074X25.4X381
Swing Motor Model MP24BA
Output of Swing Motor W 1.5
Fuse A 5
Sound Pressure Level (SH/H/M/L/SL) dB (A) 56/54/51/49/-
Sound Power Level (SH/H/M/L/SL) dB (A) 66/64/61/59/-
Dimension (WXHXD) mm 1350X326X253
Dimension of Carton Box (LXWXH) mm 1438X418X343
Dimension of Package (LXWXH) mm 1441X421X358
Net Weight kg 20
Gross Weight kg 27

Lennox LM036CI-100P232-1X Specifications

General

Brand	Lennox
Model	LM036CI-100P232-1X
Category	Air Conditioner
Language	English
