Lennox Merit 10HPB Series User Manual

Page 9
Transitioning from Vertical to Horizontal
Runs of Refrigerant Piping
Liquid Line
Vapor Line
Wrapped in
Armaflex
Strap Liquid Line
To Vapor Line
Metal
Sleeve
Anchored Heavy
Nylon Wire Tie
Automotive
Muffler-Type
Hanger
Wall
Stud
Wall
Stud
Liquid Line
Vapor Line
Wrapped in
Armaflex
Strap Liquid Line
To Vapor Line
Metal
Sleeve
Figure 9
Outside Unit Placement and Installation
Figure 10
Install unit away from windows .
Two 90° elbows
installed in line set
will reduce line set
vibration.

Lennox Merit 10HPB Series Specifications

General

Brand	Lennox
Model	Merit 10HPB Series
Category	Heat Pump
Language	English
