Lennox MHA012S4S-1P User Manual

21
7.3.10. Heating - 018 (208/230V)
Outdoor
Temperature - °F
(Dry Bulb)
Indoor Temperature - °F (Dry Bulb)
60°F 65°F 70°F 75°F
Total
mBtuh
Total
mBtuh
Total
mBtuh
Total
mBtuh
–13 6.96 6.69 6.46 6.27
–5 8.30 7.97 7.69 7.38
0 9.23 8.82 8.55 8.25
5 10.25 9.81 9.50 9.21
17 11.92 11.42 11.04 10.54
19.4 12.40 11.90 11.49 10.97
24.8 13.12 12.60 12.15 11.67
32 13.84 13.29 12.80 12.29
35 14.77 14.23 13.70 13.22
39.2 16.28 15.58 15.05 14.45
44.6 18.33 17.54 16.93 16.08
47 19.81 18.88 18.28 17.27
53.6 21.20 20.20 19.54 18.56
57 21.79 20.85 20.12 19.32
7.3.11. Cooling - 024 (208/230V)
Outdoor
Temperature - °F
(Dry Bulb)
Indoor Temperature - °F (Dry Bulb / Wet Bulb)
65°F / 54°F 70°F / 59°F 75°F / 63°F 80°F / 67°F
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
–13 18.76 14.06 19.78 14.81 20.90 15.83 22.47 17.19
–5 20.06 15.12 21.38 16.13 22.59 16.80 24.16 18.14
–4 20.34 14.76 21.94 15.92 23.05 16.73 24.66 18.10
0 21.23 15.30 22.75 16.40 23.64 17.06 25.42 18.33
5 21.53 17.12 23.08 18.36 24.25 19.25 25.94 20.46
15 21.18 17.10 22.98 18.55 24.01 19.29 25.68 20.55
25 21.22 16.54 22.36 17.43 23.63 18.36 25.41 19.45
35 20.90 16.27 22.29 17.35 23.55 18.34 25.18 19.31
45 20.59 15.52 22.21 16.75 23.33 17.59 24.95 18.82
55 20.64 14.98 22.13 16.06 22.99 16.68 24.72 17.94
65 20.33 14.66 21.80 15.72 22.90 16.51 24.49 17.66
75 20.02 15.92 21.72 17.27 22.69 18.04 24.26 19.30
85 20.17 16.28 21.25 17.16 22.46 18.13 24.15 19.50
95 19.95 15.55 21.28 16.58 22.48 17.52 24.04 18.73
105 18.94 14.75 20.43 15.91 21.47 16.71 22.96 17.88
110 18.02 14.67 19.32 15.72 20.18 16.34 21.58 17.33
115 16.75 15.44 17.96 16.56 18.77 17.08 20.18 18.29
122 15.32 14.68 16.62 15.93 17.36 16.64 18.56 17.80

Lennox MHA012S4S-1P Specifications

General

Cooling Capacity (BTU/hr)	12, 000
Voltage (V)	208/230
Phase	1
Cooling Capacity	12, 000 BTU/hr
Refrigerant Type	R-410A
Voltage	208/230V
