Page 28
TABLE 14
Maximum Allowable Exhaust Vent Pipe Length
3
Without Insulation In Unconditioned Space For
Winter Design Temperatures Single - Stage High Efficiency Furnace
Winter Design
Temperatures
1
°F (°C)
Vent Pipe
Diameter
Unit Input Size
045 070 090 110
32 to 21
(0 to -6)
PVC
2
PP PVC
2
PP PVC
2
PP PVC
2
PP
1-1/2 in. 20 N/A 20 N/A N/A N/A NAA N/A
2 in. 18 16 31 28 50 48 30 30
2-1/2 in. 13 N/A 24 N/A 42 N/A 36 N/A
3 in. 9 9 18 18 35 35 29 29
20 to 1
(-7 to -17)
1-1/2 in. 15 N/A 20 N/A N/A N/A N/A N/A
2 in 9 8 18 16 32 29 27 24
2-1/2 in. 5 N/A 13 N/A 24 N/A 20 N/A
3 in. N/A N/A 8 8 19 19 14 14
0 to -20
(-18 to -29)
1-1/2 in. 10 N/A 15 N/A N/A N/A N/A N/A
2 in. 5 N/A 12 10 22 19 18 15
2-1/2 in. N/A N/A 7 N/A 15 N/A 12 N/A
3 in. N/A N/A N/A N/A 10 10 7 7
1
Refer to 99% Minimum Design Temperature table provided in the current edition of the ASHRAE Fundamentals Handbook.
2
Poly-Propylene vent pipe (PP) by Duravent and Centrotherm.
NOTE - Concentric terminations are the equivalent of 5' and should be considered when measuring pipe length.
NOTE - Maximum uninsulated vent lengths listed may include the termination(vent pipe exterior to the structure) and cannot exceed 5 linear feet or the
maximum allowable intake or exhaust vent length listed in table 12 or 13 which ever is less.
NOTE - If insulation is required in an unconditioned space, it must be located on the pipe closest to the furnace. See figure29.
3
Vent length in the table is equivalent length. Each elbow is equivalent to 5ft of straight pipe length and should be included in measuring total pipe length
