ML196UHE Parts Identication
FIGURE 1
NOTE - This manual is the property of the homeowner
and must be left with the equipment user.
Notice to Homeowner
This furnace is equipped with safety devices that protect
you and your property. If one or more of these devices is
activated, furnace operation will stop. If your home is left
unattended for an extended period of time, equipment op-
eration must be checked periodically.
If this is not possible, the water supply to the house should be
shut o and the pipes should be drained. This will prevent prob-
lems associated with a NO HEAT condition (frozen pipes, etc.)
CAUTION
Before attempting to perform any service or maintenance,
turn the electrical power to unit OFF at disconnect switch.
TOP CAP
BLOWER ACCESS PANEL
AIR INTAKE COLLAR
BLOWER MOTOR
FLUE COLLAR
HEAT EXCHANGER
PRESSURE SWITCH
GAS VALVE
INTEGRATED CONTROL
COMBUSTION AIR INDUCER
UPPER ACCESS PANEL
