Lennox MPA036S4M-1P

Lennox Mini-Split Service Manual / Page 65
MCFA Indoor Units Clearances
24”
(610)
24
(610)
FRONT VIEW
SIDE VIEW
SIDE VIEW
SUPPLY
AIR
SUPPLY
AIR
24”
(610)
(Service Clearance
Front of Unit)
DROP CEILING
3/4”
(19)
WALL WALL
CEILING APPLICATIONS
CEILING AND FLOOR APPLICATIONS
FLOOR APPLICATIONS
Unit Flush with Wall
1”
(25.4)
1”
(25.4)
WALL
FLOOR
