MULTI-ZONE SYSTEM COMBINATIONS
NOTE - For multi-zone systems, the total capacity of all indoor units must be 66% to 133% of the outdoor unit capacity.
Outdoor Unit
Model No.
Number
of
Zones
Indoor Unit
Capacity
Nominal Cooling Capacity at Rated
System Capacity (Btuh)
Nominal Heating Capacity at Rated
System Capacity (Btuh)
#1 #2 #3 #4 #5 #1 #2 #3 #4 #5 #1 #2 #3 #4 #5
MPA018S4M
1
1 012 - - - - - - - - - - - - 11,977 - - - - - - - - - - - - 11,373 - - - - - - - - - - - -
2
009 009 - - - - - - - - - 9,000 9,000 - - - - - - - - - 9,250 9,250 - - - - - - - - -
009 012 - - - - - - - - - 8,379 10,313 - - - - - - - - - 8,538 10,508 - - - - - - - - -
012 012 - - - - - - - - - 9,450 9,450 - - - - - - - - - 9,735 9,735 - - - - - - - - -
MPA030S4M
1
1 018 - - - - - - - - - - - - 18,345 - - - - - - - - - - - - 19,730 - - - - - - - - - - - -
2
009 009 - - - - - - - - - 9,258 9,258 - - - - - - - - - 10,961 10,961 - - - - - - - - -
009 012 - - - - - - - - - 9,115 11,219 - - - - - - - - - 10,564 13,002 - - - - - - - - -
009 018 - - - - - - - - - 8,803 17,944 - - - - - - - - - 10,521 21,448 - - - - - - - - -
012 012 - - - - - - - - - 11,521 11,521 - - - - - - - - - 12,605 12,605 - - - - - - - - -
012 018 - - - - - - - - - 10,327 17,105 - - - - - - - - - 12,379 20,503 - - - - - - - - -
018 018 - - - - - - - - - 15,390 15,390 - - - - - - - - - 18,453 18,453 - - - - - - - - -
3
009 009 009 - - - - - - 8,915 8,915 8,915 - - - - - - 10,656 10,656 10,656 - - - - - -
009 009 012 - - - - - - 9,244 9,244 11,512 - - - - - - 10,234 10,234 12,596 - - - - - -
009 012 012 - - - - - - 8,681 10,684 10,684 - - - - - - 9,605 11,821 11,821 - - - - - -
009 009 018 - - - - - - 7,316 7,316 14,632 - - - - - - 8,197 8,197 16,394 - - - - - -
012 012 012 - - - - - - 9,755 9,755 9,755 - - - - - - 10,929 10,929 10,929 - - - - - -
MPA036S4M
2
009 018 - - - - - - - - - 8,788 17,913 - - - - - - - - - 9,540 19,447 - - - - - - - - -
012 012 - - - - - - - - - 10,287 10,287 - - - - - - - - - 11,864 11,864 - - - - - - - - -
012 018 - - - - - - - - - 10,052 16,649 - - - - - - - - - 10,913 18,074 - - - - - - - - -
018 018 - - - - - - - - - 17,200 17,200 - - - - - - - - - 18,240 18,240 - - - - - - - - -
3
009 009 009 - - - - - - 8,900 8,900 8,900 - - - - - - 9,476 9,476 9,476 - - - - - -
009 009 012 - - - - - - 8,265 8,265 10,172 - - - - - - 8,972 8,972 11,043 - - - - - -
009 009 018 - - - - - - 8,518 8,518 17,364 - - - - - - 9,033 9,033 18,414 - - - - - -
009 012 012 - - - - - - 9,228 11,357 11,357 - - - - - - 10,301 12,679 12,679 - - - - - -
009 012 018 - - - - - - 8,202 10,094 16,719 - - - - - - 8,347 10,273 17,015 - - - - - -
009 018 018 - - - - - - 7,640 15,575 15,575 - - - - - - 7,664 15,624 15,624 - - - - - -
012 012 012 - - - - - - 10,648 10,648 10,648 - - - - - - 11,886 11,886 11,886 - - - - - -
012 012 018 - - - - - - 9,901 9,901 16,399 - - - - - - 10,031 10,031 16,614 - - - - - -
012 018 018 - - - - - - 8,995 14,898 14,898 - - - - - - 9,175 15,197 15,197 - - - - - -
4
009 009 009 009 - - - 9,000 9,000 9,000 9,000 - - - 9,000 9,000 9,000 9,000 - - -
009 009 009 012 - - - 9,371 9,371 9,371 11,534 - - - 9,031 9,031 9,031 11,115 - - -
009 009 009 018 - - - 8,204 8,204 8,204 16,723 - - - 7,902 7,902 7,902 16,109 - - -
009 009 012 012 - - - 8,887 8,887 10,937 10,937 - - - 8,564 8,564 10,540 10,540 - - -
009 009 012 018 - - - 8,062 8,062 9,923 16,435 - - - 7,823 7,823 9,628 15,946 - - -
009 012 012 012 - - - 8,809 10,842 10,842 10,842 - - - 8,485 10,444 10,444 10,444 - - -
012 012 012 012 - - - 10,334 10,334 10,334 10,334 - - - 9,954 9,954 9,954 9,954 - - -
1
One outdoor unit may be matched with one indoor unit for single zone applications. A second indoor unit can be added at a later date for multi-zone applications.
