Lennox NEOSYS NAC 200

• 58 •
NAC 600 / 640
2025 15
2280 15
258
±5
(In1)
158
±5
(Out1)
275
±5
(Out2)
227
±5
(In2)
2180 ± 5
1069 ± 50
1222 15 568 5
150 51270 51275 51000 5
289
5
6680 15
50
100
800 5
1950 5
6175 5
1000
140 5250
5
125 5
182 5
2957 5
1069 50
1898 50
868 50
In2
In1 Out1/2
10 x 20
D1/->/D5
G1/->/G5
D1/G1
D2/G2
D3/G3
D4/G4
D5/G5
:
Ø
In 1
In 2
:
Out 1 :
Out 2 :
G1/D1 G2/D2 G3/D3 G4/D4 G5/G5
NAC 600
424 493 476 369 315
477 555 535 416 354
NAC 640
426 496 478 371 316
479 558 538 418 356
Application Guide / NEOSYS-AGU-1801-E
DIMENSIONAL DATA
LEGEND:
Gravity center
Chilled water inlet - Unit without hydraulic module
Ø 6" Victaulic
Chilled water inlet - Unit with all hydraulic module
Chilled water outlet - Unit without hydraulic module / with variable water fl ow hydraulic module (eDrive)
Chilled water outlet - Unit with hydraulic module
LOAD DITRIBUTION
(Kg - Lennox recommends load distribution as detailed below.)
More detailed load distributions available on page xxx
Without hydraulic module
With high pressure double pump
Without hydraulic module
With high pressure double pump
