Lennox NEOSYS NAC 200

• 59 •
NAC 680 / 760
G1 G2 G3 G4 G5 G6 G7 D1 D2 D3 D4 D5 D6 D7
NAC 680 480 480 480 480 480 480 480 480 480 480 480 480 480 480
NAC 760 490 490 490 490 490 490 490 490 490 490 490 490 490 490
1460 1460 1460 1460 1460 1460 140
4520±15
9040±15
2230±5
2280±15
1964±15
370±5
261±5
265
245
265
245
289
In
Out
Out
In
VOIR DETAIL K
o 250 x 125
o 250 x 125
25
60
G1/->/G8 D1/->/D8 D7/G7 D6/G6 D5/G5 D4/G4 D3/G3 D2/G2 D1/G1
IN
OUT
:
Application Guide /NEOSYS-AGU-1801-E
DIMENSIONAL DATA
LOAD DITRIBUTION
(Kg - Operating weights with dual pump hydraulic module)
Lennox recommends load distribution as detailed below
Note: In case of single main power connection (option), main power supply and disconnect switch are located at the right side of the
unit.
LEGENDE:
Water inlet
Water outlet
