Lennox NEOSYS NAC 200

• 60 •
NAC 840 / 960 / 1080
1540 1540 1540 1540 1540 1540 1540 160
5550±15
11100±5
2230±5
2280±15
1962±15
370±5
261±5
265
245
265
245
289
In
Out
Out
In
o 250 x 125o 250 x 125
25
60
G1/->/G8 D1/->/D8
D8/G8
D7/G7 D6/G6 D5/G5 D4/G4 D3/G3 D2/G2 D1/G1
G1 G2 G3 G4 G5 G6 G7 G8 D1 D2 D3 D4 D5 D6 D7 D8
NAC 840 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500
NAC 960 510 510 510 510 510 510 510 510 510 510 510 510 510 510 510 510
NAC 1080 510 510 510 510 510 510 510 510 510 510 510 510 510 510 510 510
IN
OUT
:
Application Guide / NEOSYS-AGU-1801-E
DIMENSIONAL DATA
LOAD DITRIBUTION
(Kg - Operating weights with dual pump hydraulic module)
Lennox recommends load distribution as detailed below
Note: In case of single main power connection (option), main power supply and disconnect switch are located at the right side of the
unit.
LEGENDE:
Water inlet
Water outlet
