Lennox PRODIGY M2

Page 5
Menu Interface
Table 2 shows the major levels of the menu interface.
Many of these options have more levels and are described
in the following sections that detail DISPLAY, SERVICE,
DATA, and SETTINGS.
Use rectangular button
to progress to next
lower level (i.e. Level 1 to Level 2).
Use left arrow
toback up" to the next higher level
(i.e. Level 2 to Level 1).
Use the up/down
arrows to move within a level
and change values of selected item.
Table 2. Menu Interface
Level 1 Level 2 Level 3
NOTE − Features and options not currently available are greyed out in
the manual and will show a message of N/A" on the display
(display
area)
ALARM
SILENCE (push any button to silence)
STATUS
SILENCE (push any button to silence)
MODE
BLOWER
COOLING
FREE COOLING
FRESH AIR COOL
FRESH AIR HEAT
HEATING
HVAC OFF
IDLE
MORNING
WARMUP
M2 FAILED TO
RESPOND
PRE−COOL
PRE INSTALL
REHEAT
SMOKE
TEST
CALLS
TSTAT Y1, etc
BACNET Y1, etc
LONTALK Y1, etc
LCONN Y1, etc
BUILDING Y1, etc
USB
WRITING USB
WRITING ALARM/STATUS LOG
USB COMPLETE
SER-
VICE
USE ARROWS TO MOVE
TEST
GUIDED
BLOWER
FANS
COOL
HEAT
DAMPER
REHEAT
SENSORS
OUTPUTS
CONTROLLER
OFFLINE
LOCKOUT
BLOWER ONLY
COOLING ONLY
HEATING ONLY
RESET
IN /
OUTPUTS
ZONING
SENSORS
RELAYS
NETWORK
OUTPUTS
REPLACE
FILTER
BELT
UV LAMP
FANS
BLOWER
COMPRESSOR
REPORT
MAKE REPORT
READ INSTALL
READ FACTORY
Table 2. Menu Interface (cont’d)
Level 1 Level 2 Level 3
DATA
USE ARROWS TO MOVEUSE ARROWS TO MOVEUSE ARROWS TO MOVEUSE ARROWS TO MOVE
RUNTIMES
POWER ON
FILTER: XX HRS
BELT: XX HRS
UV LAMP: XX HRS
BLOWER: XX HRS − XX CYC
COOLING
HEATING
FREE COOLING: XX HRS − XX
CYC
FANS
EXHAUST
REHEAT: XX HRS − XX CYC
HISTORY
ALARMS
STATUS
LAST USB
READ INSTALL RPT
CLEAR HISTORY
SENSORS
(also
accessible
thru In /
Outputs)
TSTAT
BRPM:XX
DPOS:XX%
OAT:XXºF
RAT:XXºF
DAT:XXºF
ZAT:XXºF
IAQ:XX PPM
SMK:OFF/ON
RH:XX%
IE:XX MA
OE:XX MA
GLO:OFF/ON
DI2:OFF/ON
DI3:OFF/ON
DI4:OFF/ON
NETWORK
LCONN ADDRESS
BACNET ADDRESS
LONTALK ADDRESS
FACTORY
READ M2 SOFTWARE
VERSION
READ DB SOFTWARE
VERSION
READ FACTORY RPT
CATALOG NO.
MODEL NO.
SERIAL NO.
SET-
TINGS
USE ARROWS TO MOVE
UNIT
UNIT NO.
DATE/TIME
UNITS F/C
SETPOINTS
COOLING
HEATING
DAMPER
REHEAT
EXHAUST
IAQ
CONTROL
GUIDED SETUP
LOCAL
THERMOSTAT
LCONN
BACNET
LONTALK
MSAV
REHEAT
OPTIONS
RESERVED
INSTALL
NEW M2
DAMPER
FLOAT SW
BLOWER PROVING SW
PHASE MONITOR
UV LAMP
ELECTRIC HEAT STAGES
UPDATE DISPLAY SOFTWARE
