Page 58 - IOM / ROOF-TOP FLEXY™ Series
DESCRIPTION OF PARAMETERS
Parameters are defined for the time slot. Select by instruction 08 setting.
0 = DAY / 1 = WEEKEND / 2 = NIGHT / 3 = unused / 4 = MORNING / 5 =MIDDAY / 6 = EVENING / 7 = BMS.
Instruction Description
09 Day of the week of start of setting . From 1 to 7, 1 = Sunday.
10 Hour of start of setting
11 Minutes for start of setting
12 Day of the end of setting
13 Hour of end of setting
14 Minutes of end of setting
15 Setpoint in heating
16 Setpoint in air conditioning
17 Defined if the hygrometry values below are taken as absolute (ON) or relative (OFF).
18 Minimum relative humidity of ambient air (%)
19 Maximum relative humidity of ambient air (%)
20 Minimum absolute humidity of ambient air (g/kg of dry air)
21 Maximum absolute humidity of ambient air (g/kg of dry air)
22 Relative value of minimum flow of new air (%)
23 Fan operation in regulation zone *. ON on OFF off
24 Fan operation in neutral zone*. ON on OFF off
25 Automatic fan operation in neutral zone*. In this zone after operation in air-conditioning mode, the fan is off. If after
one hour the ambient air is still in this zone the fan is started up again.
26 On ON, forces low speed fan operation in the regulation zone*.
27 On ON, forces low speed fan operation in the neutral zone*.
28 On ON, forces automatic low speed operation. If the unit is in air-conditioning or dehumidifying mode and less
than 3 compressors are in use the fan then switches to low speed.
29 Low noise
30 Instruction used to force operation in the current setting
CLIMATIC™ PARAMETERS
* The regulation zone is defined for a temperature less than
the heating instruction or greater than the air-conditioning
instruction. The neutral zone is between these 2 values.
NOTE : The end of the night slot night is defined by the start
of the morning slot : this is why there is no need to define the
end of the night slot in the table below
Setpoint
value DAY WEEK-END NIGHT MORNING MIDDAY EVENING BMS
for KP02 = 0 = 1 = 2 = 4 = 5 = 6 = 7
9 -7-----
10 - 22 22 6 12 19 -
11 -00000-
12 -2-----
13 -6-61219-
14 -0-000-
15 23.0 30.0 30.0 23.0 23.0 23.0 23.0
16 19.0 10.0 10.0 19.0 19.0 19.0 19.0
17 Off Off Off Off Off Off Off
18 0000000
19 100 100 100 100 100 100 100
20 0.0 0.0 0.0 0.0 0.0 0.0 0.0
21 30.0 30.0 30.0 30.0 30.0 30.0 30.0
22 20 0 0 0 20 20 20
23 On On On On On On On
24 Off Off Off Off Off Off Off
25 Off Off Off Off Off Off Off
26 Off Off Off Off Off Off Off
27 Off Off Off Off Off Off Off
28 Off Off Off Off Off Off Off
29 Off Off Off Off Off Off Off
30 Off Off Off Off Off Off Off
