IOM / ROOF-TOP FLEXY™ Series - Page 57
CLIMATIC™ PARAMETERS
ON - OFF
The unit is declared On if setpoint 6 (C06) is ON.
The unit can be stopped by a remote control command by
hard contact.
On KP12 extension card - see chapter on BMS contact kit.
For certain configurations a CLIMATIC™ system actuator can
be used to control an external function (option: Client).
The Client option is declared On if setpoint 7 (C07) is ON.
DEFINITION OF TIME SLOT PARAMETERS
The CLIMATIC™ allows you to programme 5 operating zones
per day, in addition to an idle zone for the weekend.
Slot activation is :
- automatically controlled by the CLIMATIC™, if you have
defined these time parameters for each slot
- forced manually by action on the controller (instructions
02/03 and 04 for KP02).
- forced by the BMS contacts kit ( see this chapter).
- forced by the computer connection.
The five available time slots are :
WEEK-END
NIGHT
MORNING
NOON
EVENING
If none of the time slots listed above is active, the active slot
is :
DAY
A particular time slot :
BMS is activated if the unit is connected to a
computer network.
0123456789101112131415161718192021222324
With the KP07 :
- Go directly to the screen concerning the time slot to be
modified, enter the parameters described below on the
screen (see organisation of screens in KP07chapter).
With the KP02 :
- The slot to be set up must first be defined by the 08
instruction. Enter the information below then return to
the 08 instruction to go to the next slot.
Friday 22h. Monday 8h.
