SCA120 PARTS ARRANGEMENT
FIGURE 1
EVAPORATOR
COIL
BLOWER
MOTOR
CONDENSER FANS
CONDENSER
COILS
COMPRESSORS (2)
BLOWER
CONDENSATE
DRAIN
FILTERS
(SIX − 16 x 25 X 2")
ECONOMIZER
DAMPERS
(OPTIONAL)
IMC
ELECTRIC HEAT
(Optional)
FILTER DRIERS
SUPPLY AIR VFD
(OPTIONAL)
FIGURE 2
SCA240/SCB288 PARTS ARRANGEMENT
BLOWERS
(2)
L
E
N
O
X
N
FILTERS
(TWELVE − 20 X 20 X 2")
ELECTRIC HEAT
(Optional)
EVAPORATOR
COIL
BLOWER
MOTOR
CONDENSER
FANS (6)
CONDENSER
COILS
COMPRESSORS (4)
CONDENSATE
DRAIN
ECONOMIZER
DAMPERS
(OPTIONAL)
IMC
FILTER
DRIERS
SUPPLY AIR VFD
(OPTIONAL)

Lennox SCA Series Specifications

General

SEER	Up to 16
Refrigerant	R-410A
Operating Voltage (VAC)	208/230
Compressor Type	Scroll
Cooling Capacity (BTU/h)	18, 000 - 60, 000
