Page 4
SPECIFICATIONS 10 TON
General
Data
Nominal Tonnage 10 Ton 10 Ton
Model No. SCA120H4B SCA120H4M
Blower Type Constant Air Volume MSAV (Multi-Stage Air
Volume) Supply Fan Option
Efciency Type High High
Cooling
Performance
Gross Cooling Capacity - Btuh 123,000 123,000
1
Net Cooling Capacity - Btuh 119,000 119,000
AHRI Rated Air Flow - cfm 3700 3700
Total Unit Power 9.7 9.8
1
EER (Btuh/Watt) 12.3 12.1
2
IEER (Btuh/Watt) 12.8 15.2
Refrigerant Charge Furnished
R-410A
Circuit 1 22 lbs. 8 oz. 24 lbs. 0 oz.
Circuit 2 21 lbs. 0 oz. 21 lbs. 8 oz.
3
Sound Rating Number (dB) 88 88
Electric Heat Options Available See page 2
Compressor Type (No.) Scroll (2) Scroll (2)
Condenser Coil Net face area - sq. ft. 47.1 47.1
Tube diameter - in. 3/8 3/8
Number of rows 3 3
Fins per inch 14 14
Condenser
Fan(s)
Motor horsepower (3) 1/3 (3) 1/3
Motor rpm 1075 1075
Total Motor watts 940 940
Diameter - in. (3) 24 (3) 24
Number of blades 3 3
Total air volume - cfm 11,800 11,800
Evaporator Coil Net face area - sq. ft. 15.6 15.6
Tube diameter - in. 3/8 3/8
Number of rows 4 4
Fins per inch 14 14
Drain connection - no. & size (1) 1 (1) 1
Expansion device type Thermostatic Expansion Valve
4
Indoor
Blower
Nominal motor output 3 3
Maximum usable motor output 3.45 - - -
RPM Range (Standard Static) Drive #1 - 660-900 rpm Drive #3 - 350-1050 rpm
RPM Range (High Static) Drive #2 - 865-1080 rpm - - -
Wheel nominal diameter x width - in. (1) 15 x 15 (1) 15 x 15
Filters Type of lter MERV 7 or equivalent
Number and size - in. (6) 16 x 25 x 2
Electrical characteristics 208/230V, 460V, or 575V - 60 hertz - 3 phase
NOTE - Net capacity includes evaporator blower motor heat deduction. Gross capacity does not include evaporator blower motor heat deduction.
1
Certied in accordance with the ULE certication program, which is based on AHRI Standard 340/360, 95°F outdoor air temperature and 80°F db/67°F wb entering
evaporator air; minimum external duct static pressure.
2
Integrated Energy Efciency Ratio certied and tested according to AHRI Standard 340/360.
3
Sound Rating Number rated in accordance with test conditions included in AHRI Standard 270.
4
Using total air volume and system static pressure requirements determine from blower performance tables rpm and motor output required. Maximum usable output of
motors furnished are shown. In Canada, nominal motor output is also maximum usable motor output. If motors of comparable output are used, be sure to keep within
the service factor limitations outlined on the motor nameplate.
