Page 34
FIGURE 19
EHA 15, 30, 45, 60, AND 90 KW
ELECTRIC HEAT SECTION PARTS ARRANGEMENT
PRIMARY ELECTRIC
HEAT LIMIT
S15(1
ST
SECTION)
S107(2
ND
SECTION)
HEATING ELEMENTS
HE1 − HE14
CONTROL WIRE
HARNESS
ELECTRIC HEAT
VESTIBULE
