505232 06/07
Page 12
Fan Program
This function allows the user to select whether the indoor blower operates
in ON or AUTO modes during each programmed event period. For
example, the indoor blower could be programmed to run in AUTO mode
during the WAKE and MORN event periods and run in ON mode during the
EVE and NIGHT event periods. The indoor blower may be set to run
continuously during the occupied times to improve indoor air quality.
1. From the home screen press
MENU. Use the UP or DOWN
buttons until FAN is highlighted.
Press SELECT.
2. Use the UP or DOWN buttons to
highlight FAN PROGRAM. Press
SELECT.
3. Use the UP or DOWN buttons to
highlight the days or day you want
to program. You can choose
MON to SUN, MON to FRI, SAT
to SUN, or individual days of the
week. Press SELECT.
4. Use the UP or DOWN buttons to
highlight the event you want to
program.
5. Press SELECT. ON/AUTO is
highlighted. Use the UP or
DOWN buttons to highlight the
ON or AUTO. Press SELECT.
Press SET to select desired val-
ue. Press FINISHED when com-
plete.
MAIN MENU
DAY / TIME
FAN ↑
USER SETTINGS ⏐
INSTALLER SETTINGS
HOME SELECT
FAN MENU
FAN SETTINGS
FAN PROGRAM
HOME SELECT
SELECT PROGRAM DAYS
MON TO SUN
MON TO FRI ⏐
SAT TO SUN ↓
MONDAY
MAIN MENU SELECT
MON−SUN PROGRAM
FAN
WAKE 6:30 AM AUTO
MORN 8:30 AM AUTO
EVE 4:30 PM AUTO
NIGHT 10:30 PM AUTO
MAIN MENU SELECT
MON−SUN PROGRAM
FAN
WAKE 6:30 AM AUTO
MORN 8:30 AM AUTO
EVE 4:30 PM AUTO
NIGHT 10:30 PM AUTO
MAIN MENU SELECT
MON−SUN PROGRAM
FAN
WAKE 6:30 AM AUTO
MORN 8:30 AM AUTO
EVE 4:30 PM AUTO
NIGHT 10:30 PM AUTO
MAIN MENU SELECT
MON−SUN PROGRAM
FAN
WAKE 6:30 AM ON
MORN 8:30 AM AUTO
EVE 4:30 PM AUTO
NIGHT 10:30 PM AUTO
MAIN MENU SELECT
To Next Page
