SignatureStat t Thermostat
Page 5
Programming for Full Week or Work Week
The programming process for MON TO SUN, MON TO FRI, and SAT TO
SUN is identical.
Full WeekThe least complex program is the full week MON TO SUN"
program, wherein the events for every day of the week are the same. If this
is chosen, follow steps 1 through 6, below, setting time and temperature for
each event. One time through all the events completes the programming
process.
Work WeekNext in complexity to the full week program is the work week
program wherein the events are set for a typical work week (MON TO FRI)
and different events are set for the weekend (SAT TO SUN). If MON TO FRI
is chosen, follow steps 1 through 6, below, setting time and temperature for
each event. Then repeat the same process for SAT TO SUN to complete
the programming process.
1. From the home screen, press MENU. Use the Up or Down button to
highlight PROGRAM. Press Select.
2. Select the appropriate time span
from the program days list. For
this example, choose the MON
TO SUN program days and press
Select.
3. Use Up/Down buttons to select
the event to program. The unit
can be set for two or four events
per day. After choosing an event
to program, press select. See
User Settings" for Events Per
Day selection.
4. The time for the first event should
be highlighted. Use the UP or
DOWN button to change the time.
Press SET TIME.
5. The heating setpoint for the first
event is highlighted. Use the UP
or DOWN button to change the
desired temperature. Press SET
HEAT.
6. The cooling setpoint for the first event will be highlighted. Use the UP
or DOWN button to change the desired temperature. Press SET
COOL. The next event, e.g. MORN will then be highlighted. Continue
programming until all event times and heat/cool settings are set as
desired.
Programming Day-by-Day
Individual day programming, MONDAY through SUNDAY, is done similar
to full week or work week. However, with this mode, a down arrow" ap-
pears next to the SELECT. Using the down button, an additional option is
available, COPY. After programming events for a selected day, for example
MONDAY, you can select COPY. Another screen with the remaining days
of the week appears. Use the up/down arrow buttons to scroll to another
day, for example, THURSDAY, and press YES/NO. YES will appear next to
THURSDAY. (Another press of the YES/NO button clears the YES" dis-
play [toggles back to NO]). Do this for each day to which you want to copy
the individual day’s program.
SELECT PROGRAM DAYS
MON TO SUN
MON TO FRI ⎮
SAT TO SUN ↓
MONDAY
MAIN MENU SELECT
MON−SUN PROGRAM
HEAT COOL
WAKE 6:30 AM 70 78
MORN 8:30 AM 62 85
EVE 4:30 PM 70 78
NIGHT 10:30 PM 62 82
MAIN MENU SELECT
MON−SUN PROGRAM
HEAT COOL
WAKE 6:30 AM 70 78
MORN 8:30 AM 62 85
EVE 4:30 PM 70 78
NIGHT 10:30 PM 62 82
BACK SET TIME
MON−SUN PROGRAM
HEAT COOL
WAKE 6:30 AM 70 78
MORN 8:30 AM 62 85
EVE 4:30 PM 70 78
NIGHT 10:30 PM 62 82
BACK SET HEAT
