Page 43
HEATING COMPONENTS
Ignitor
Burner Assembly
Sensor
Gas Valve
Burner Box Front Panel
Screw
(remove and panel will
swing open and off)
Rollout Switch
Rollout Switch
(alternate location)
Rollout Switch
FIGURE 15
