XC14 - 1.5 to 5 Ton Air Conditioner / Page 16
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC14-030-230 RFC 28,800 15.20 13.00 C33-43 G61MPV-36B-071 3130569
XC14-030-230 RFC 28,400 14.00 12.00 C33-43 3130504
XC14-030-230 RFC 27,000 13.00 11.50 CH33-19 3130507
XC14-030-230 RFC 27,600 13.50 11.70 CH33-25A 3130508
XC14-030-230 RFC 27,800 14.20 12.20 CH33-25B G61MPV-36B-045 3130549
XC14-030-230 RFC 28,000 14.70 12.70 CH33-25B G61MPV-36B-070 3130550
XC14-030-230 RFC 28,000 14.70 12.70 CH33-25B G61MPV-36B-071 3130572
XC14-030-230 RFC 27,600 13.50 11.70 CH33-25B 3130509
XC14-030-230 RFC 28,200 14.00 12.00 CH33-31A 3130510
XC14-030-230 RFC 28,400 14.70 12.50 CH33-31B G61MPV-36B-045 3130553
XC14-030-230 RFC 28,600 15.20 13.00 CH33-31B G61MPV-36B-070 3130554
XC14-030-230 RFC 28,600 15.20 13.00 CH33-31B G61MPV-36B-071 3130573
XC14-030-230 RFC 28,200 14.00 12.00 CH33-31B 3130511
XC14-030-230 RFC 27,400 13.50 11.70 CH33-36A 3130512
XC14-030-230 RFC 27,600 14.20 12.20 CH33-36B G61MPV-36B-045 3130557
XC14-030-230 RFC 27,800 14.70 12.50 CH33-36B G61MPV-36B-070 3130558
XC14-030-230 RFC 27,800 14.70 12.50 CH33-36B G61MPV-36B-071 3130574
XC14-030-230 RFC 27,400 13.50 11.70 CH33-36B 3130513
XC14-030-230 RFC 28,200 14.50 12.50 CH33-42 G61MPV-36B-045 3130560
XC14-030-230 RFC 28,400 15.00 12.70 CH33-42 G61MPV-36B-070 3130561
XC14-030-230 RFC 28,400 15.00 12.70 CH33-42 G61MPV-36B-071 3130575
XC14-030-230 RFC 28,000 13.70 11.70 CH33-42 3130514
XC14-030-230 RFC 27,400 13.50 11.70 CR33-24 G61MPV-36B-045 3130544
XC14-030-230 RFC 27,600 14.00 12.20 CR33-24 G61MPV-36B-070 3130545
XC14-030-230 RFC 27,600 14.00 12.20 CR33-24 G61MPV-36B-071 3130571
XC14-030-230 RFC 27,200 13.20 11.50 CR33-24 3130506
XC14-030-230 RFC 28,000 14.50 12.20 CR33-30/36 G61MPV-36B-045 3130542
XC14-030-230 RFC 28,200 15.00 12.70 CR33-30/36 G61MPV-36B-070 3130543
XC14-030-230 RFC 28,200 15.00 12.70 CR33-30/36 G61MPV-36B-071 3130570
XC14-030-230 RFC 27,600 13.70 11.70 CR33-30/36 3130505
XC14-030-230 TXV 27,600 14.50 12.00 C33-25 G61MPV-36B-045 3131936
XC14-030-230 TXV 28,000 15.00 12.50 C33-25 G61MPV-36B-070 3131937
XC14-030-230 TXV 28,000 15.00 12.50 C33-25 G61MPV-36B-071 3131938
XC14-030-230 TXV 28,200 15.20 12.70 C33-25 SL280UH070V36A 4035257
XC14-030-230 TXV 28,200 15.20 12.70 C33-25 SL280UH070XV36A 4037862
XC14-030-230 TXV 28,200 15.50 13.00 C33-25 SL280UH090V36B 4035258
XC14-030-230 TXV 28,200 15.20 12.70 C33-25 SLP98UH070V36B 4020371
XC14-030-230 TXV 27,600 13.70 11.70 C33-25 3132074
XC14-030-230 TXV 27,000 14.00 11.70 C33-30 G61MPV-36B-045 3131942
XC14-030-230 TXV 27,200 14.50 12.20 C33-30 G61MPV-36B-070 3131943
XC14-030-230 TXV 27,200 14.50 12.20 C33-30 G61MPV-36B-071 3131944
XC14-030-230 TXV 27,600 14.70 12.50 C33-30 SL280UH070V36A 4035259
XC14-030-230 TXV 27,600 14.70 12.50 C33-30 SL280UH070XV36A 4037863
XC14-030-230 TXV 27,600 15.00 12.70 C33-30 SL280UH090V36B 4035256
XC14-030-230 TXV 27,600 14.50 12.50 C33-30 SLP98UH070V36B 4020372
XC14-030-230 TXV 26,800 13.50 11.20 C33-30 3132075
XC14-030-230 TXV 28,200 15.00 12.50 C33-31 G61MPV-36B-045 3131948
XC14-030-230 TXV 28,400 15.50 12.70 C33-31 G61MPV-36B-070 3131949
XC14-030-230 TXV 28,400 15.50 12.70 C33-31 G61MPV-36B-071 3131950
XC14-030-230 TXV 29,000 15.70 13.20 C33-31 SL280UH070V36A 4035260
XC14-030-230 TXV 29,000 15.70 13.20 C33-31 SL280UH070XV36A 4037864
XC14-030-230 TXV 29,000 16.00 13.50 C33-31 SL280UH090V36B 4035261
XC14-030-230 TXV 28,800 15.70 13.00 C33-31 SLP98UH070V36B 4020373
XC14-030-230 TXV 28,000 14.20 12.00 C33-31 3132076
XC14-030-230 TXV 27,600 14.50 12.20 C33-36 G61MPV-36B-045 3131954
XC14-030-230 TXV 27,800 15.20 12.50 C33-36 G61MPV-36B-070 3131955
XC14-030-230 TXV 27,800 15.20 12.50 C33-36 G61MPV-36B-071 3131956
XC14-030-230 TXV 27,800 15.20 12.70 C33-36 G61MPV-36C-090 3131957
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC14 Specifications

General

Compressor Type	Single-Stage
Refrigerant	R-410A
Energy Star Certified	Yes
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Cooling Capacity	1.5 - 5 tons
EER Rating	Up to 13.00
Warranty	10-year limited warranty on compressor, 5-year limited warranty on parts
Compressor	Scroll
