Lennox XC14 User Manual

XC14 - 1.5 to 5 Ton Air Conditioner / Page 18
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC14-030-230 TXV 28,400 15.00 12.50 CH33-31B G61MPV-36B-045 3132001
XC14-030-230 TXV 28,600 15.20 13.00 CH33-31B G61MPV-36B-070 3132087
XC14-030-230 TXV 28,600 15.20 13.00 CH33-31B G61MPV-36B-071 3132088
XC14-030-230 TXV 28,200 14.20 12.00 CH33-31B 3132090
XC14-030-230 TXV 28,400 15.50 13.00 CH33-36 G61MPV-36C-090 3986993
XC14-030-230 TXV 28,200 15.20 12.70 CH33-36 SL280UH070V36A 3929133
XC14-030-230 TXV 28,200 15.20 12.70 CH33-36 SL280UH070XV36A 4037856
XC14-030-230 TXV 28,200 15.50 13.00 CH33-36 SL280UH090V36B 3929134
XC14-030-230 TXV 28,200 15.20 12.70 CH33-36 SLP98UH070V36B 4020391
XC14-030-230 TXV 28,600 15.70 13.00 CH33-36 SLP98UH090V36C 4020392
XC14-030-230 TXV 27,400 13.70 11.70 CH33-36A 3132091
XC14-030-230 TXV 27,600 14.50 12.20 CH33-36B G61MPV-36B-045 3132004
XC14-030-230 TXV 27,800 15.00 12.50 CH33-36B G61MPV-36B-070 3132005
XC14-030-230 TXV 27,800 15.00 12.50 CH33-36B G61MPV-36B-071 3132006
XC14-030-230 TXV 27,400 13.70 11.70 CH33-36B 3132092
XC14-030-230 TXV 28,200 15.00 12.50 CH33-42 G61MPV-36B-045 3132009
XC14-030-230 TXV 28,400 15.50 12.70 CH33-42 G61MPV-36B-070 3132010
XC14-030-230 TXV 28,400 15.50 12.70 CH33-42 G61MPV-36B-071 3132011
XC14-030-230 TXV 28,800 16.00 13.20 CH33-42 SL280UH090V36B 3929135
XC14-030-230 TXV 28,800 15.70 13.00 CH33-42 SLP98UH070V36B 4020393
XC14-030-230 TXV 28,000 14.20 12.00 CH33-42 3132093
XC14-030-230 TXV 29,000 16.00 13.20 CH33-43 G61MPV-36C-090 3132013
XC14-030-230 TXV 29,600 16.20 13.70 CH33-43 SL280UH090V36B 3929136
XC14-030-230 TXV 29,600 16.20 13.50 CH33-43 SL280UH090V48B 4249222
XC14-030-230 TXV 29,600 16.00 13.50 CH33-43 SLP98UH070V36B 4020394
XC14-030-230 TXV 29,600 16.50 13.70 CH33-43 SLP98UH090V36C 4020395
XC14-030-230 TXV 28,800 15.50 13.00 CH33-44/48 G61MPV-36C-090 3987287
XC14-030-230 TXV 28,800 15.50 13.00 CH33-44/48 G61MPV-36C-090 3987286
XC14-030-230 TXV 28,800 16.00 13.20 CH33-44/48 SL280UH090V48B 4249223
XC14-030-230 TXV 27,200 14.00 11.70 CR33-24 G61MPV-36B-045 3132017
XC14-030-230 TXV 27,400 14.50 12.20 CR33-24 G61MPV-36B-070 3132018
XC14-030-230 TXV 27,400 14.50 12.20 CR33-24 G61MPV-36B-071 3132019
XC14-030-230 TXV 26,600 14.20 12.00 CR33-24 SL280DF070V36A 3929270
XC14-030-230 TXV 26,400 14.20 12.00 CR33-24 SL280DF090V48B 3929137
XC14-030-230 TXV 26,800 14.00 12.00 CR33-24 SLP98DF070V36B 4020396
XC14-030-230 TXV 27,200 13.70 11.50 CR33-24 3132094
XC14-030-230 TXV 28,000 14.70 12.20 CR33-30/36 G61MPV-36B-045 3132023
XC14-030-230 TXV 28,200 15.20 12.70 CR33-30/36 G61MPV-36B-070 3132024
XC14-030-230 TXV 28,200 15.20 12.70 CR33-30/36 G61MPV-36B-071 3132025
XC14-030-230 TXV 28,200 15.00 12.70 CR33-30/36 G61MPV-36C-090 3132026
XC14-030-230 TXV 28,600 15.20 12.70 CR33-30/36 SL280DF070V36A 3929138
XC14-030-230 TXV 28,200 15.50 13.00 CR33-30/36 SL280DF090V48B 3929139
XC14-030-230 TXV 28,400 15.50 13.00 CR33-30/36 SLP98DF070V36B 4020397
XC14-030-230 TXV 28,600 15.70 13.20 CR33-30/36 SLP98DF090V36C 4020398
XC14-030-230 TXV 27,800 14.00 11.70 CR33-30/36 3132096
XC14-030-230 TXV 27,600 14.50 12.00 CX34-25 G61MPV-36B-045 3132030
XC14-030-230 TXV 28,000 15.00 12.50 CX34-25 G61MPV-36B-070 3132031
XC14-030-230 TXV 28,000 15.00 12.50 CX34-25 G61MPV-36B-071 3132032
XC14-030-230 TXV 28,200 15.20 12.70 CX34-25 SL280UH070V36A 3929116
XC14-030-230 TXV 28,200 15.20 12.70 CX34-25 SL280UH070XV36A 4037857
XC14-030-230 TXV 28,200 15.50 13.00 CX34-25 SL280UH090V36B 3929117
XC14-030-230 TXV 28,200 15.20 12.70 CX34-25 SLP98UH070V36B 4020380
XC14-030-230 TXV 27,600 13.70 11.70 CX34-25 3132097
XC14-030-230 TXV 27,000 14.00 11.70 CX34-30 G61MPV-36B-045 3132036
XC14-030-230 TXV 27,200 14.50 12.20 CX34-30 G61MPV-36B-070 3132037
XC14-030-230 TXV 27,200 14.50 12.20 CX34-30 G61MPV-36B-071 3132038
XC14-030-230 TXV 27,600 14.70 12.50 CX34-30 SL280UH070V36A 3929118
XC14-030-230 TXV 27,600 14.70 12.50 CX34-30 SL280UH070XV36A 4037858
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC14 Specifications

General

Compressor Type	Single-Stage
Refrigerant	R-410A
Energy Star Certified	Yes
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Cooling Capacity	1.5 - 5 tons
EER Rating	Up to 13.00
Warranty	10-year limited warranty on compressor, 5-year limited warranty on parts
SEER Rating	Up to 16.00
Compressor	Scroll
