Lennox XC14 User Manual

XC14 - 1.5 to 5 Ton Air Conditioner / Page 19
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC14-030-230 TXV 27,600 15.00 12.70 CX34-30 SL280UH090V36B 3929119
XC14-030-230 TXV 27,600 14.70 12.50 CX34-30 SLP98UH070V36B 4020381
XC14-030-230 TXV 26,800 13.50 11.20 CX34-30 3132098
XC14-030-230 TXV 28,200 15.20 12.70 CX34-31 G61MPV-36B-045 3132042
XC14-030-230 TXV 28,400 15.50 12.70 CX34-31 G61MPV-36B-070 3132043
XC14-030-230 TXV 28,400 15.50 12.70 CX34-31 G61MPV-36B-071 3132044
XC14-030-230 TXV 29,000 15.70 13.20 CX34-31 SL280UH070V36A 3929120
XC14-030-230 TXV 29,000 15.70 13.20 CX34-31 SL280UH070XV36A 4037859
XC14-030-230 TXV 29,000 16.00 13.50 CX34-31 SL280UH090V36B 3929121
XC14-030-230 TXV 28,800 15.70 13.00 CX34-31 SLP98UH070V36B 4020382
XC14-030-230 TXV 28,000 14.20 12.00 CX34-31 3132099
XC14-030-230 TXV 27,600 14.50 12.20 CX34-36 G61MPV-36B-045 3132048
XC14-030-230 TXV 27,800 15.20 12.50 CX34-36 G61MPV-36B-070 3132049
XC14-030-230 TXV 27,800 15.20 12.50 CX34-36 G61MPV-36B-071 3132050
XC14-030-230 TXV 27,800 15.20 12.70 CX34-36 G61MPV-36C-090 3132051
XC14-030-230 TXV 28,200 15.50 13.00 CX34-36 SL280UH070V36A 3929122
XC14-030-230 TXV 28,200 15.50 13.00 CX34-36 SL280UH070XV36A 4037860
XC14-030-230 TXV 28,200 15.50 13.00 CX34-36 SL280UH090V36B 3929123
XC14-030-230 TXV 28,200 15.20 12.70 CX34-36 SLP98UH070V36B 4020383
XC14-030-230 TXV 28,400 15.50 13.00 CX34-36 SLP98UH090V36C 4020384
XC14-030-230 TXV 27,400 13.70 11.70 CX34-36 3132100
XC14-030-230 TXV 28,200 14.70 12.50 CX34-38 G61MPV-36B-045 3132055
XC14-030-230 TXV 28,400 15.50 12.70 CX34-38 G61MPV-36B-070 3132056
XC14-030-230 TXV 28,400 15.50 12.70 CX34-38 G61MPV-36B-071 3132057
XC14-030-230 TXV 29,200 16.00 13.20 CX34-38 SL280UH070V36A 3929124
XC14-030-230 TXV 29,200 16.00 13.20 CX34-38 SL280UH070XV36A 4037861
XC14-030-230 TXV 29,200 16.00 13.50 CX34-38 SL280UH090V36B 3929125
XC14-030-230 TXV 29,200 16.00 13.20 CX34-38 SL280UH090V48B 4249219
XC14-030-230 TXV 29,000 15.70 13.20 CX34-38 SLP98UH070V36B 4020385
XC14-030-230 TXV 28,200 14.20 12.00 CX34-38 3132101
XC14-030-230 TXV 27,600 14.50 12.20 CX34-42 G61MPV-36B-045 3132060
XC14-030-230 TXV 27,800 15.20 12.50 CX34-42 G61MPV-36B-070 3132061
XC14-030-230 TXV 27,800 15.20 12.50 CX34-42 G61MPV-36B-071 3132062
XC14-030-230 TXV 28,200 15.50 13.00 CX34-42 SL280UH090V36B 3929126
XC14-030-230 TXV 28,200 15.20 12.70 CX34-42 SLP98UH070V36B 4020386
XC14-030-230 TXV 27,400 13.70 11.70 CX34-42 3132102
XC14-030-230 TXV 28,600 15.20 12.70 CX34-43 G61MPV-36B-045 3132065
XC14-030-230 TXV 28,800 15.70 13.00 CX34-43 G61MPV-36B-070 3132066
XC14-030-230 TXV 28,800 15.70 13.00 CX34-43 G61MPV-36B-071 3132067
XC14-030-230 TXV 28,800 15.50 13.00 CX34-43 G61MPV-36C-090 3132069
XC14-030-230 TXV 29,200 16.00 13.50 CX34-43 SL280UH090V36B 3929127
XC14-030-230 TXV 29,400 16.00 13.50 CX34-43 SL280UH090V48B 4249220
XC14-030-230 TXV 29,200 15.70 13.20 CX34-43 SLP98UH070V36B 4020387
XC14-030-230 TXV 29,400 16.20 13.50 CX34-43 SLP98UH090V36C 4020388
XC14-030-230 TXV 28,400 14.20 12.00 CX34-43 3132103
XC14-036-230 RFC 33,400 14.20 12.20 C33-31 G61MPV-36B-045 3130887
XC14-036-230 RFC 33,400 14.20 12.20 C33-31 G61MPV-36B-070 3130888
XC14-036-230 RFC 33,400 14.20 12.20 C33-31 G61MPV-36B-071 3130943
XC14-036-230 RFC 33,200 13.70 11.70 C33-31 3130860
XC14-036-230 RFC 32,400 14.00 12.00 C33-36 G61MPV-36B-045 3130879
XC14-036-230 RFC 32,600 14.20 12.00 C33-36 G61MPV-36B-070 3130880
XC14-036-230 RFC 32,600 14.20 12.00 C33-36 G61MPV-36B-071 3130941
XC14-036-230 RFC 32,200 13.20 11.50 C33-36 3130861
XC14-036-230 RFC 33,400 14.20 12.20 C33-38 G61MPV-36B-045 3130883
XC14-036-230 RFC 33,400 14.20 12.20 C33-38 G61MPV-36B-070 3130884
XC14-036-230 RFC 33,400 14.20 12.20 C33-38 G61MPV-36B-071 3130942
XC14-036-230 RFC 33,400 13.70 11.70 C33-38 3130859
XC14-036-230 RFC 32,400 14.00 12.00 C33-42 G61MPV-36B-045 3130890
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC14 Specifications

General

Compressor Type	Single-Stage
Refrigerant	R-410A
Energy Star Certified	Yes
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Cooling Capacity	1.5 - 5 tons
EER Rating	Up to 13.00
Warranty	10-year limited warranty on compressor, 5-year limited warranty on parts
SEER Rating	Up to 16.00
Compressor	Scroll
