XC14 - 1.5 to 5 Ton Air Conditioner / Page 26
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC14-036-230 TXV 35,000 16.00 13.20 CX34-43 SLP98UH090V48C 4020438
XC14-036-230 TXV 34,400 14.20 12.00 CX34-43 3130594
XC14-036-230 TXV 34,000 14.70 12.50 CX34-44/48 G61MPV-36B-045 3130635
XC14-036-230 TXV 34,000 14.70 12.50 CX34-44/48 G61MPV-36B-070 3130636
XC14-036-230 TXV 34,000 14.70 12.50 CX34-44/48 G61MPV-36B-071 3130739
XC14-036-230 TXV 34,600 15.20 12.70 CX34-44/48 G61MPV-60C-090 3130638
XC14-036-230 TXV 34,600 15.50 12.70 CX34-44/48 G61MPV-60C-110 3130639
XC14-036-230 TXV 34,600 15.20 12.70 CX34-44/48 G61MPV-60C-111 3130640
XC14-036-230 TXV 34,400 15.70 13.00 CX34-44/48 SL280UH090V36B 3929155
XC14-036-230 TXV 34,600 15.70 13.00 CX34-44/48 SL280UH090V48B 3929156
XC14-036-230 TXV 35,000 15.70 13.00 CX34-44/48 SL280UH090V60C 3929157
XC14-036-230 TXV 34,600 15.70 13.00 CX34-44/48 SL280UH090XV48B 4038627
XC14-036-230 TXV 35,000 15.70 13.00 CX34-44/48 SL280UH090XV60C 4235409
XC14-036-230 TXV 34,800 15.50 13.00 CX34-44/48 SL280UH110V60C 3929158
XC14-036-230 TXV 34,800 15.50 13.00 CX34-44/48 SL280UH110XV60C 4040414
XC14-036-230 TXV 34,200 15.50 12.70 CX34-44/48 SLP98UH070V36B 4020439
XC14-036-230 TXV 34,600 15.50 13.00 CX34-44/48 SLP98UH090V36C 4020440
XC14-036-230 TXV 34,400 15.70 13.00 CX34-44/48 SLP98UH090V48C 4020441
XC14-036-230 TXV 33,800 14.00 11.70 CX34-44/48 3130596
XC14-036-230 TXV 34,600 15.00 12.50 CX34-49 G61MPV-36C-090 3130763
XC14-036-230 TXV 35,400 15.70 13.20 CX34-49 G61MPV-60C-090 3130642
XC14-036-230 TXV 39,000 15.50 13.00 CX34-49 G61MPV-60C-091 4207544
XC14-036-230 TXV 35,600 15.70 13.20 CX34-49 G61MPV-60C-110 3130643
XC14-036-230 TXV 35,600 15.70 13.20 CX34-49 G61MPV-60C-111 3130644
XC14-036-230 TXV 35,800 16.00 13.20 CX34-49 SL280UH090V60C 3929159
XC14-036-230 TXV 35,800 16.00 13.20 CX34-49 SL280UH090XV60C 4235410
XC14-036-230 TXV 35,400 15.70 13.20 CX34-49 SL280UH110V60C 3929160
XC14-036-230 TXV 35,400 15.70 13.20 CX34-49 SL280UH110XV60C 4040415
XC14-036-230 TXV 35,400 16.00 13.20 CX34-49 SLP98UH090V36C 4020442
XC14-036-230 TXV 35,200 16.00 13.20 CX34-49 SLP98UH090V48C 4020443
XC14-036-230 TXV 34,600 14.20 12.00 CX34-49 3130595
XC14-036-230 TXV 35,000 15.50 13.00 CX34-50/60C G61MPV-60C-090 3130646
XC14-036-230 TXV 35,000 15.50 13.00 CX34-50/60C G61MPV-60C-110 3130647
XC14-036-230 TXV 35,000 15.50 13.00 CX34-50/60C G61MPV-60C-111 3130648
XC14-036-230 TXV 35,400 16.00 13.20 CX34-50/60C SL280UH090V60C 3929161
XC14-036-230 TXV 35,400 16.00 13.20 CX34-50/60C SL280UH090XV60C 4235411
XC14-036-230 TXV 35,200 15.70 13.00 CX34-50/60C SL280UH110V60C 3929162
XC14-036-230 TXV 35,200 15.70 13.00 CX34-50/60C SL280UH110XV60C 4040416
XC14-036-230 TXV 35,000 15.70 13.00 CX34-50/60C SLP98UH090V36C 4020444
XC14-036-230 TXV 34,800 15.70 13.00 CX34-50/60C SLP98UH090V48C 4020445
XC14-036-230 TXV 34,000 14.20 11.70 CX34-50/60C 3130597
XC14-036-230 TXV 34,400 14.50 12.00 CX34-60D 3387496
XC14-041-230 TXV 38,500 15.70 13.00 C33-43 G61MPV-60C-090 3869123
XC14-041-230 TXV 39,000 15.20 13.00 C33-43 G61MPV-60C-091 3869124
XC14-041-230 TXV 39,000 15.70 13.00 C33-43 G61MPV-60C-110 3869125
XC14-041-230 TXV 39,000 15.70 13.00 C33-43 G61MPV-60C-111 3869126
XC14-041-230 TXV 39,000 16.00 13.00 C33-43 SL280UH090V60C 3869130
XC14-041-230 TXV 39,000 16.00 13.00 C33-43 SL280UH090XV60C 4235238
XC14-041-230 TXV 39,000 16.00 13.00 C33-43 SL280UH110V60C 3869131
XC14-041-230 TXV 39,000 16.00 13.00 C33-43 SL280UH110XV60C 4040424
XC14-041-230 TXV 37,800 14.50 12.20 C33-43 3869132
XC14-041-230 TXV 38,500 14.70 12.50 C33-49 3869133
XC14-041-230 TXV 39,000 16.00 13.00 CBX27UH-048 3869134
XC14-041-230 TXV 39,500 16.00 13.00 CBX32MV-048 3869135
XC14-041-230 TXV 39,000 16.00 13.00 CBX40UHV-048 3869136
XC14-041-230 TXV 39,500 15.70 13.00 CH33-43 SL280UH090V36B 4253810
XC14-041-230 TXV 39,500 15.70 13.00 CH33-43 SL280UH090V48B 4253808
XC14-041-230 TXV 39,500 15.70 13.00 CH33-43 SL280UH090XV48B 4253809
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC14 Specifications

General

Compressor Type	Single-Stage
Refrigerant	R-410A
Energy Star Certified	Yes
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Cooling Capacity	1.5 - 5 tons
EER Rating	Up to 13.00
Warranty	10-year limited warranty on compressor, 5-year limited warranty on parts
SEER Rating	Up to 16.00
Compressor	Scroll
