Lennox XC14 User Manual

XC14 - 1.5 to 5 Ton Air Conditioner / Page 27
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC14-041-230 TXV 39,000 15.70 13.00 CH33-43 SLP98UH090V36C 4154588
XC14-041-230 TXV 39,000 15.70 13.00 CH33-43 SLP98UH090V48C 4154589
XC14-041-230 TXV 39,000 15.70 13.00 CH33-43 SLP98UH090V60C 4154591
XC14-041-230 TXV 38,500 16.00 13.00 CH33-43 SLP98UH110V60C 4154593
XC14-041-230 TXV 39,000 15.70 13.00 CH33-43C G61MPV-60C-090 3869138
XC14-041-230 TXV 39,000 15.70 13.00 CH33-43C G61MPV-60C-110 3869139
XC14-041-230 TXV 39,500 16.00 13.00 CH33-43C SL280UH090V60C 3869142
XC14-041-230 TXV 39,500 16.00 13.00 CH33-43C SL280UH090XV60C 4235239
XC14-041-230 TXV 39,000 15.70 13.00 CH33-43C SL280UH110V60C 3869143
XC14-041-230 TXV 39,000 15.70 13.00 CH33-43C SL280UH110XV60C 4040425
XC14-041-230 TXV 38,500 15.20 13.00 CH33-48 SLP98UH090V36C 4253811
XC14-041-230 TXV 38,500 15.50 13.00 CH33-48 SLP98UH090V48C 4253812
XC14-041-230 TXV 39,000 14.50 12.50 CH33-50/60C 4253813
XC14-041-230 TXV 38,000 15.20 13.00 CR33-50/60 G61MPV-60C-090 3869146
XC14-041-230 TXV 38,000 15.20 13.00 CR33-50/60 G61MPV-60C-091 3869147
XC14-041-230 TXV 38,000 15.70 13.00 CR33-50/60 G61MPV-60C-110 3869148
XC14-041-230 TXV 38,000 15.50 13.00 CR33-50/60 G61MPV-60C-111 3869149
XC14-041-230 TXV 38,500 16.00 13.00 CR33-50/60 SL280DF090V60C 3869152
XC14-041-230 TXV 39,000 16.00 13.00 CR33-50/60 SL280DF110V60C 3869198
XC14-041-230 TXV 39,000 15.70 13.00 CX34-43 G61MPV-60C-090 3869154
XC14-041-230 TXV 39,000 15.20 13.00 CX34-43 G61MPV-60C-091 3869155
XC14-041-230 TXV 39,000 15.70 13.00 CX34-43 G61MPV-60C-110 3869156
XC14-041-230 TXV 39,000 15.70 13.00 CX34-43 G61MPV-60C-111 3869157
XC14-041-230 TXV 39,000 16.00 13.00 CX34-43 SL280UH090V60C 3869161
XC14-041-230 TXV 39,000 16.00 13.00 CX34-43 SL280UH090XV60C 4235240
XC14-041-230 TXV 39,000 16.00 13.00 CX34-43 SL280UH110V60C 3869162
XC14-041-230 TXV 39,000 16.00 13.00 CX34-43 SL280UH110XV60C 4040426
XC14-041-230 TXV 38,500 15.50 13.00 CX34-43 SLP98UH090V36C 4154580
XC14-041-230 TXV 39,000 15.70 13.00 CX34-43 SLP98UH090V48C 4154582
XC14-041-230 TXV 39,000 15.50 13.00 CX34-43 SLP98UH090V60C 4154584
XC14-041-230 TXV 38,500 16.00 13.00 CX34-43 SLP98UH110V60C 4154586
XC14-041-230 TXV 38,500 14.50 12.20 CX34-43 3869163
XC14-041-230 TXV 40,000 16.00 13.00 CX34-49 SL280UH090V60C 4253814
XC14-041-230 TXV 39,500 16.00 13.00 CX34-49 SL280UH110V60C 4253815
XC14-041-230 TXV 39,500 16.00 13.00 CX34-49 SLP98UH110V60C 4253816
XC14-041-230 TXV 39,000 14.70 12.50 CX34-49 3869164
XC14-041-230 TXV 40,000 16.00 13.00 CX34-62C SL280UH090V60C 4253817
XC14-041-230 TXV 40,000 16.00 13.00 CX34-62C SL280UH110V60C 4253818
XC14-041-230 TXV 40,000 16.00 13.00 CX34-62C SLP98UH090V36C 4253819
XC14-041-230 TXV 40,000 16.00 13.00 CX34-62C SLP98UH090V48C 4253820
XC14-041-230 TXV 40,000 16.00 13.00 CX34-62C SLP98UH090V60C 4253821
XC14-041-230 TXV 40,000 16.00 13.00 CX34-62C SLP98UH110V60C 4253822
XC14-042-230 RFC 39,000 13.70 11.70 C33-36 G61MPV-60C-090 1236951
XC14-042-230 RFC 39,500 13.70 11.70 C33-36 G61MPV-60C-091 1236953
XC14-042-230 RFC 39,500 13.70 12.00 C33-36 G61MPV-60C-110 1236952
XC14-042-230 RFC 39,500 13.70 12.00 C33-36 G61MPV-60C-111 1236954
XC14-042-230 RFC 39,000 13.00 11.20 C33-36 1236943
XC14-042-230 RFC 40,000 13.70 12.00 C33-38 G61MPV-36B-070 1236956
XC14-042-230 RFC 40,000 13.70 12.00 C33-38 G61MPV-36B-071 1248170
XC14-042-230 RFC 40,000 13.20 11.50 C33-38 1236944
XC14-042-230 RFC 40,000 13.20 11.50 C33-38B 3293422
XC14-042-230 RFC 38,500 13.20 11.50 C33-42 G61MPV-36B-070 1236958
XC14-042-230 RFC 38,500 13.20 11.50 C33-42 G61MPV-36B-071 1248171
XC14-042-230 RFC 39,000 13.00 11.20 C33-42 1236945
XC14-042-230 RFC 40,500 14.00 12.00 C33-43 G61MPV-36B-070 1236960
XC14-042-230 RFC 40,500 14.00 12.00 C33-43 G61MPV-36B-071 1248172
XC14-042-230 RFC 41,000 14.70 12.50 C33-43 G61MPV-60C-090 1236963
XC14-042-230 RFC 41,500 14.50 12.50 C33-43 G61MPV-60C-091 1236965
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC14 Specifications

General

Compressor Type	Single-Stage
Refrigerant	R-410A
Energy Star Certified	Yes
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Cooling Capacity	1.5 - 5 tons
EER Rating	Up to 13.00
Warranty	10-year limited warranty on compressor, 5-year limited warranty on parts
SEER Rating	Up to 16.00
Compressor	Scroll
