Lennox XC14 User Manual

XC14 - 1.5 to 5 Ton Air Conditioner / Page 31
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC14-042-230 TXV 41,500 14.70 12.50 CH33-43 G61MPV-60C-091 1235396
XC14-042-230 TXV 41,500 15.00 12.70 CH33-43 G61MPV-60C-110 1235395
XC14-042-230 TXV 41,500 14.70 12.70 CH33-43 G61MPV-60C-111 1235397
XC14-042-230 TXV 42,000 14.70 12.70 CH33-43 SL280UH090V36B 3929206
XC14-042-230 TXV 42,000 15.00 12.70 CH33-43 SL280UH090V48B 3929207
XC14-042-230 TXV 42,000 15.20 13.00 CH33-43 SL280UH090V60C 3929208
XC14-042-230 TXV 42,000 15.00 12.70 CH33-43 SL280UH090XV48B 4038647
XC14-042-230 TXV 42,000 15.20 13.00 CH33-43 SL280UH090XV60C 4235421
XC14-042-230 TXV 41,500 15.20 12.70 CH33-43 SL280UH110V60C 3929209
XC14-042-230 TXV 41,500 15.20 12.70 CH33-43 SL280UH110XV60C 4040433
XC14-042-230 TXV 42,000 14.20 12.20 CH33-43 SLP98UH070V36B 4020486
XC14-042-230 TXV 41,500 14.70 12.50 CH33-43 SLP98UH090V36C 4020487
XC14-042-230 TXV 41,500 14.70 12.70 CH33-43 SLP98UH090V48C 4020488
XC14-042-230 TXV 42,000 14.70 12.70 CH33-43 SLP98UH090V60C 4020489
XC14-042-230 TXV 41,500 15.00 12.70 CH33-43 SLP98UH110V60C 4020490
XC14-042-230 TXV 41,000 13.70 11.70 CH33-43 1235387
XC14-042-230 TXV 41,000 14.50 12.20 CH33-44/48 SL280UH090V36B 3929210
XC14-042-230 TXV 41,000 14.70 12.50 CH33-44/48 SL280UH090V48B 3929211
XC14-042-230 TXV 41,000 14.70 12.50 CH33-44/48 SL280UH090XV48B 4038648
XC14-042-230 TXV 41,000 14.70 12.50 CH33-48 G61MPV-60C-090 1235400
XC14-042-230 TXV 41,500 14.20 12.20 CH33-48 G61MPV-60C-091 1235402
XC14-042-230 TXV 41,500 14.70 12.50 CH33-48 G61MPV-60C-110 1235401
XC14-042-230 TXV 41,500 14.70 12.50 CH33-48 G61MPV-60C-111 1235403
XC14-042-230 TXV 41,500 14.70 12.50 CH33-48 SL280UH090V60C 3929212
XC14-042-230 TXV 41,500 14.70 12.50 CH33-48 SL280UH090XV60C 4235422
XC14-042-230 TXV 41,000 14.70 12.50 CH33-48 SL280UH110V60C 3929213
XC14-042-230 TXV 41,000 14.70 12.50 CH33-48 SL280UH110XV60C 4040434
XC14-042-230 TXV 41,000 14.50 12.20 CH33-48 SLP98UH090V36C 4020491
XC14-042-230 TXV 41,000 14.70 12.50 CH33-48 SLP98UH090V48C 4020492
XC14-042-230 TXV 41,500 14.50 12.50 CH33-48 SLP98UH090V60C 4020493
XC14-042-230 TXV 41,500 14.70 12.50 CH33-48 SLP98UH110V60C 4020494
XC14-042-230 TXV 41,000 13.70 11.70 CH33-48 1235388
XC14-042-230 TXV 42,000 14.70 12.70 CH33-49 G61MPV-60C-090 1235406
XC14-042-230 TXV 42,000 14.70 12.50 CH33-49 G61MPV-60C-091 1235408
XC14-042-230 TXV 42,000 15.00 12.70 CH33-49 G61MPV-60C-110 1235407
XC14-042-230 TXV 42,000 14.70 12.70 CH33-49 G61MPV-60C-111 1235409
XC14-042-230 TXV 42,000 15.00 12.70 CH33-49 SL280UH090V60C 3929214
XC14-042-230 TXV 42,000 15.00 12.70 CH33-49 SL280UH090XV60C 4235423
XC14-042-230 TXV 42,000 15.00 12.70 CH33-49 SL280UH110V60C 3929215
XC14-042-230 TXV 42,000 15.00 12.70 CH33-49 SL280UH110XV60C 4040435
XC14-042-230 TXV 41,500 14.70 12.50 CH33-49 SLP98UH090V36C 4020495
XC14-042-230 TXV 42,000 15.00 12.50 CH33-49 SLP98UH090V48C 4020496
XC14-042-230 TXV 42,000 14.70 12.50 CH33-49 SLP98UH090V60C 4020497
XC14-042-230 TXV 42,000 15.00 12.70 CH33-49 SLP98UH110V60C 4020498
XC14-042-230 TXV 41,500 14.00 12.00 CH33-49 1235389
XC14-042-230 TXV 41,500 14.70 12.50 CH33-50/60C G61MPV-60C-090 1235412
XC14-042-230 TXV 42,000 14.50 12.50 CH33-50/60C G61MPV-60C-091 1235414
XC14-042-230 TXV 42,000 14.70 12.70 CH33-50/60C G61MPV-60C-110 1235413
XC14-042-230 TXV 41,500 14.70 12.50 CH33-50/60C G61MPV-60C-111 1235415
XC14-042-230 TXV 42,000 15.00 12.70 CH33-50/60C SL280UH090V60C 3929216
XC14-042-230 TXV 42,000 15.00 12.70 CH33-50/60C SL280UH090XV60C 4235424
XC14-042-230 TXV 42,000 15.00 12.70 CH33-50/60C SL280UH110V60C 3929217
XC14-042-230 TXV 42,000 15.00 12.70 CH33-50/60C SL280UH110XV60C 4040436
XC14-042-230 TXV 41,500 14.00 12.00 CH33-50/60C 1235390
XC14-042-230 TXV 39,500 13.70 11.70 CR33-48 G61MPV-60C-091 3855602
XC14-042-230 TXV 39,500 13.70 11.70 CR33-48 G61MPV-60C-091 3854589
XC14-042-230 TXV 39,500 14.20 12.00 CR33-48 SL280DF090V60C 3929218
XC14-042-230 TXV 39,500 14.20 12.20 CR33-48 SL280DF110V60C 3929219
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC14 Specifications

General

Compressor Type	Single-Stage
Refrigerant	R-410A
Energy Star Certified	Yes
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Cooling Capacity	1.5 - 5 tons
EER Rating	Up to 13.00
Warranty	10-year limited warranty on compressor, 5-year limited warranty on parts
SEER Rating	Up to 16.00
Compressor	Scroll
