Lennox XC14 User Manual

XC14 - 1.5 to 5 Ton Air Conditioner / Page 32
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC14-042-230 TXV 41,000 14.70 12.50 CR33-50/60 G61MPV-60C-090 1235381
XC14-042-230 TXV 41,000 14.50 12.20 CR33-50/60 G61MPV-60C-091 1235383
XC14-042-230 TXV 41,000 14.70 12.50 CR33-50/60 G61MPV-60C-110 1235382
XC14-042-230 TXV 41,000 14.70 12.50 CR33-50/60 G61MPV-60C-111 1235384
XC14-042-230 TXV 41,000 15.00 12.70 CR33-50/60 SL280DF090V60C 3929220
XC14-042-230 TXV 41,000 15.00 12.70 CR33-50/60 SL280DF110V60C 3929221
XC14-042-230 TXV 41,000 14.50 12.50 CR33-50/60 SLP98DF090V36C 4020528
XC14-042-230 TXV 41,000 14.50 12.50 CR33-50/60 SLP98DF090V48C 4020529
XC14-042-230 TXV 41,000 14.50 12.20 CR33-50/60 SLP98DF090V60C 4020530
XC14-042-230 TXV 41,000 14.70 12.50 CR33-50/60 SLP98DF110V60C 4020531
XC14-042-230 TXV 40,500 13.70 11.70 CR33-50/60 1235378
XC14-042-230 TXV 41,000 15.00 12.70 CR33-60 G61MPV-60D-135 1235386
XC14-042-230 TXV 40,500 13.70 11.70 CR33-60 1235379
XC14-042-230 TXV 39,500 14.00 12.00 CX34-36 G61MPV-60C-090 1235294
XC14-042-230 TXV 39,500 13.70 11.70 CX34-36 G61MPV-60C-091 1235296
XC14-042-230 TXV 39,500 14.00 12.00 CX34-36 G61MPV-60C-110 1235295
XC14-042-230 TXV 39,500 14.00 12.00 CX34-36 G61MPV-60C-111 1235297
XC14-042-230 TXV 39,000 14.00 11.70 CX34-36 SL280UH090V36B 3929182
XC14-042-230 TXV 39,000 14.00 12.00 CX34-36 SL280UH090V48B 3929183
XC14-042-230 TXV 39,500 14.20 12.00 CX34-36 SL280UH090V60C 3929184
XC14-042-230 TXV 39,000 14.00 12.00 CX34-36 SL280UH090XV48B 4038643
XC14-042-230 TXV 39,500 14.20 12.00 CX34-36 SL280UH090XV60C 4235419
XC14-042-230 TXV 39,500 14.20 12.00 CX34-36 SL280UH110V60C 3929185
XC14-042-230 TXV 39,500 14.20 12.00 CX34-36 SL280UH110XV60C 4040431
XC14-042-230 TXV 39,000 13.50 11.50 CX34-36 SLP98UH070V36B 4020499
XC14-042-230 TXV 39,000 13.70 11.70 CX34-36 SLP98UH090V36C 4020500
XC14-042-230 TXV 39,500 14.00 12.00 CX34-36 SLP98UH090V48C 4020501
XC14-042-230 TXV 39,500 14.00 11.70 CX34-36 SLP98UH090V60C 4020502
XC14-042-230 TXV 39,500 14.00 12.00 CX34-36 SLP98UH110V60C 4020503
XC14-042-230 TXV 39,000 13.00 11.20 CX34-36 1235279
XC14-042-230 TXV 39,500 13.70 11.70 CX34-38 G61MPV-36B-070 1235299
XC14-042-230 TXV 39,500 13.70 11.70 CX34-38 G61MPV-36B-071 1248126
XC14-042-230 TXV 41,000 14.50 12.20 CX34-38 SL280UH090V36B 3929186
XC14-042-230 TXV 41,000 14.70 12.50 CX34-38 SL280UH090V48B 3929187
XC14-042-230 TXV 41,000 14.70 12.50 CX34-38 SL280UH090XV48B 4038644
XC14-042-230 TXV 40,500 14.00 12.00 CX34-38 SLP98UH070V36B 4020504
XC14-042-230 TXV 40,000 13.50 11.50 CX34-38 1235280
XC14-042-230 TXV 40,000 13.50 11.50 CX34-38B 3293421
XC14-042-230 TXV 38,500 13.50 11.50 CX34-42 G61MPV-36B-070 1235301
XC14-042-230 TXV 38,500 13.50 11.50 CX34-42 G61MPV-36B-071 1248127
XC14-042-230 TXV 39,000 14.00 11.70 CX34-42 SL280UH090V36B 3929188
XC14-042-230 TXV 39,000 14.00 12.00 CX34-42 SL280UH090V48B 3929189
XC14-042-230 TXV 39,000 14.00 12.00 CX34-42 SL280UH090XV48B 4038645
XC14-042-230 TXV 39,000 13.50 11.50 CX34-42 SLP98UH070V36B 4020505
XC14-042-230 TXV 39,000 13.00 11.20 CX34-42 1235281
XC14-042-230 TXV 40,500 14.20 12.00 CX34-43 G61MPV-36B-070 1235303
XC14-042-230 TXV 40,500 14.20 12.00 CX34-43 G61MPV-36B-071 1248128
XC14-042-230 TXV 41,500 14.70 12.70 CX34-43 G61MPV-60C-090 1235306
XC14-042-230 TXV 41,500 14.50 12.50 CX34-43 G61MPV-60C-091 1235308
XC14-042-230 TXV 41,500 15.00 12.70 CX34-43 G61MPV-60C-110 1235307
XC14-042-230 TXV 41,500 14.70 12.70 CX34-43 G61MPV-60C-111 1235309
XC14-042-230 TXV 41,000 14.50 12.20 CX34-43 SL280UH090V36B 3929190
XC14-042-230 TXV 41,000 14.70 12.50 CX34-43 SL280UH090V48B 3929191
XC14-042-230 TXV 41,500 15.20 12.70 CX34-43 SL280UH090V60C 3929192
XC14-042-230 TXV 41,000 14.70 12.50 CX34-43 SL280UH090XV48B 4038646
XC14-042-230 TXV 41,500 15.20 12.70 CX34-43 SL280UH090XV60C 4235420
XC14-042-230 TXV 41,500 15.00 12.70 CX34-43 SL280UH110V60C 3929193
XC14-042-230 TXV 41,500 15.00 12.70 CX34-43 SL280UH110XV60C 4040432
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC14 Specifications

General

Compressor Type	Single-Stage
Refrigerant	R-410A
Energy Star Certified	Yes
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Cooling Capacity	1.5 - 5 tons
EER Rating	Up to 13.00
Warranty	10-year limited warranty on compressor, 5-year limited warranty on parts
SEER Rating	Up to 16.00
Compressor	Scroll
