Lennox XC14 User Manual

XC14 - 1.5 to 5 Ton Air Conditioner / Page 35
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC14-047-230 TXV 45,000 15.00 12.50 CR33-60 G61MPV-60D-135 3869234
XC14-047-230 TXV 46,000 14.70 12.50 CX34-43 SL280UH090V48B 4016680
XC14-047-230 TXV 46,000 14.70 12.50 CX34-43 SL280UH090XV48B 4038654
XC14-047-230 TXV 45,000 14.50 12.20 CX34-44/48 G61MPV-60C-090 3869238
XC14-047-230 TXV 45,000 14.20 12.00 CX34-44/48 G61MPV-60C-091 3869239
XC14-047-230 TXV 45,000 14.70 12.20 CX34-44/48 G61MPV-60C-110 3869240
XC14-047-230 TXV 45,000 14.70 12.20 CX34-44/48 G61MPV-60C-111 3869241
XC14-047-230 TXV 45,000 14.50 12.20 CX34-44/48 SL280UH090V48B 4016681
XC14-047-230 TXV 45,000 14.70 12.20 CX34-44/48 SL280UH090V60C 3869244
XC14-047-230 TXV 45,000 14.50 12.20 CX34-44/48 SL280UH090XV48B 4038655
XC14-047-230 TXV 45,000 14.70 12.20 CX34-44/48 SL280UH090XV60C 4235246
XC14-047-230 TXV 45,000 14.70 12.20 CX34-44/48 SL280UH110V60C 3869245
XC14-047-230 TXV 45,000 14.70 12.20 CX34-44/48 SL280UH110XV60C 4040445
XC14-047-230 TXV 45,000 14.70 12.20 CX34-44/48 SLP98UH090V48C 4155385
XC14-047-230 TXV 45,000 14.50 12.20 CX34-44/48 SLP98UH090V60C 4155387
XC14-047-230 TXV 45,000 14.70 12.20 CX34-44/48 SLP98UH110V60C 4155389
XC14-047-230 TXV 45,000 14.20 11.70 CX34-44/48 3869246
XC14-047-230 TXV 47,000 15.00 12.50 CX34-49 G61MPV-60C-091 4151650
XC14-047-230 TXV 47,000 15.20 12.70 CX34-49 G61MPV-60C-111 4151651
XC14-047-230 TXV 47,000 15.70 13.00 CX34-49 SL280UH090V60C 4253856
XC14-047-230 TXV 47,000 15.70 13.00 CX34-49 SL280UH110V60C 4253857
XC14-047-230 TXV 47,000 15.20 12.70 CX34-49 SLP98UH090V48C 4253858
XC14-047-230 TXV 47,000 15.50 12.70 CX34-49 SLP98UH090V60C 4253859
XC14-047-230 TXV 47,000 15.50 12.70 CX34-49 SLP98UH110V60C 4253860
XC14-047-230 TXV 48,000 16.00 13.00 CX34-62C SL280UH090V60C 4253861
XC14-047-230 TXV 47,500 16.00 13.00 CX34-62C SL280UH110V60C 4253862
XC14-047-230 TXV 47,000 14.70 12.50 CX34-62C 3869247
XC14-048-230 RFC 48,000 14.20 12.00 C33-43 G61MPV-60C-090 1237052
XC14-048-230 RFC 48,000 14.00 11.70 C33-43 G61MPV-60C-091 1237054
XC14-048-230 RFC 48,000 14.20 12.00 C33-43 G61MPV-60C-110 1237053
XC14-048-230 RFC 48,000 14.20 12.00 C33-43 G61MPV-60C-111 1237055
XC14-048-230 RFC 47,500 13.70 11.50 C33-43 1237040
XC14-048-230 RFC 47,000 13.70 11.70 C33-48 G61MPV-60C-090 1237046
XC14-048-230 RFC 47,000 13.50 11.50 C33-48 G61MPV-60C-091 1237048
XC14-048-230 RFC 47,000 13.70 11.70 C33-48 G61MPV-60C-110 1237047
XC14-048-230 RFC 47,000 13.70 11.70 C33-48 G61MPV-60C-111 1237049
XC14-048-230 RFC 47,000 13.20 11.50 C33-48 1237039
XC14-048-230 RFC 48,500 14.50 12.20 C33-49 G61MPV-60C-090 1237058
XC14-048-230 RFC 48,500 14.20 12.00 C33-49 G61MPV-60C-091 1237060
XC14-048-230 RFC 48,500 14.50 12.20 C33-49 G61MPV-60C-110 1237059
XC14-048-230 RFC 48,500 14.50 12.20 C33-49 G61MPV-60C-111 1237061
XC14-048-230 RFC 48,500 13.70 11.70 C33-49 1237041
XC14-048-230 RFC 48,000 14.00 12.00 C33-50/60C G61MPV-60C-090 1237064
XC14-048-230 RFC 48,000 13.70 11.70 C33-50/60C G61MPV-60C-091 1237066
XC14-048-230 RFC 48,000 14.00 12.00 C33-50/60C G61MPV-60C-110 1237065
XC14-048-230 RFC 48,000 14.00 11.70 C33-50/60C G61MPV-60C-111 1237067
XC14-048-230 RFC 47,500 13.50 11.50 C33-50/60C 1237043
XC14-048-230 RFC 48,000 13.70 11.70 C33-60D 1237042
XC14-048-230 RFC 49,500 14.70 12.50 C33-62C G61MPV-60C-090 1237070
XC14-048-230 RFC 49,500 14.50 12.20 C33-62C G61MPV-60C-091 1237072
XC14-048-230 RFC 49,500 14.70 12.50 C33-62C G61MPV-60C-110 1237071
XC14-048-230 RFC 49,500 14.70 12.20 C33-62C G61MPV-60C-111 1237073
XC14-048-230 RFC 49,000 14.20 11.70 C33-62C 1237038
XC14-048-230 RFC 49,000 14.70 12.50 C33-62D G61MPV-60D-135 1237178
XC14-048-230 RFC 48,500 14.00 11.70 C33-62D 1237176
XC14-048-230 RFC 49,000 15.00 12.50 CH23-68 G61MPV-60D-135 1237133
XC14-048-230 RFC 48,500 13.70 11.70 CH23-68 1237098
XC14-048-230 RFC 48,000 14.00 12.00 CH33-43 G61MPV-60C-090 1237101
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC14 Specifications

General

Compressor Type	Single-Stage
Refrigerant	R-410A
Energy Star Certified	Yes
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Cooling Capacity	1.5 - 5 tons
EER Rating	Up to 13.00
Warranty	10-year limited warranty on compressor, 5-year limited warranty on parts
SEER Rating	Up to 16.00
Compressor	Scroll
