XC14 - 1.5 to 5 Ton Air Conditioner / Page 37
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC14-048-230 TXV 47,000 14.20 11.70 C33-48 SL280UH110V60C 4035318
XC14-048-230 TXV 47,000 14.20 11.70 C33-48 SL280UH110XV60C 4040456
XC14-048-230 TXV 46,500 14.00 11.50 C33-48 SLP98UH090V48C 4020535
XC14-048-230 TXV 47,000 14.00 11.70 C33-48 SLP98UH090V60C 4020536
XC14-048-230 TXV 46,500 14.00 11.50 C33-48 SLP98UH110V60C 4020537
XC14-048-230 TXV 46,500 13.50 11.20 C33-48 1235465
XC14-048-230 TXV 48,500 14.70 12.20 C33-49 G61MPV-60C-090 1235484
XC14-048-230 TXV 48,500 14.20 12.00 C33-49 G61MPV-60C-091 1235486
XC14-048-230 TXV 48,500 14.70 12.20 C33-49 G61MPV-60C-110 1235485
XC14-048-230 TXV 48,500 14.50 12.20 C33-49 G61MPV-60C-111 1235487
XC14-048-230 TXV 48,500 14.70 12.20 C33-49 SL280UH090V60C 4035319
XC14-048-230 TXV 48,500 14.70 12.20 C33-49 SL280UH090XV60C 4235566
XC14-048-230 TXV 48,000 14.70 12.20 C33-49 SL280UH110V60C 4035320
XC14-048-230 TXV 48,000 14.70 12.20 C33-49 SL280UH110XV60C 4040457
XC14-048-230 TXV 48,500 14.50 12.20 C33-49 SLP98UH090V48C 4020538
XC14-048-230 TXV 48,500 14.50 12.20 C33-49 SLP98UH090V60C 4020539
XC14-048-230 TXV 48,500 14.50 12.20 C33-49 SLP98UH110V60C 4020540
XC14-048-230 TXV 48,500 14.00 11.70 C33-49 1235467
XC14-048-230 TXV 47,500 14.20 11.70 C33-50/60C G61MPV-60C-090 1235582
XC14-048-230 TXV 47,500 14.00 11.70 C33-50/60C G61MPV-60C-091 1235584
XC14-048-230 TXV 47,500 14.20 12.00 C33-50/60C G61MPV-60C-110 1235583
XC14-048-230 TXV 47,500 14.00 11.70 C33-50/60C G61MPV-60C-111 1235585
XC14-048-230 TXV 47,500 14.20 12.00 C33-50/60C SL280UH090V60C 4035321
XC14-048-230 TXV 47,500 14.20 12.00 C33-50/60C SL280UH090XV60C 4235567
XC14-048-230 TXV 47,500 14.20 12.00 C33-50/60C SL280UH110V60C 4035322
XC14-048-230 TXV 47,500 14.20 12.00 C33-50/60C SL280UH110XV60C 4040458
XC14-048-230 TXV 47,500 14.00 11.70 C33-50/60C SLP98UH090V48C 4020541
XC14-048-230 TXV 47,500 14.00 11.70 C33-50/60C SLP98UH090V60C 4020542
XC14-048-230 TXV 47,500 14.00 11.70 C33-50/60C SLP98UH110V60C 4020543
XC14-048-230 TXV 47,000 13.70 11.50 C33-50/60C 1235579
XC14-048-230 TXV 48,500 14.70 12.20 C33-60D G61MPV-60D-135 1235495
XC14-048-230 TXV 48,000 15.00 12.50 C33-60D SL280UH135V60D 4035323
XC14-048-230 TXV 48,500 14.70 12.20 C33-60D SLP98UH135V60D 4020544
XC14-048-230 TXV 48,000 14.00 11.70 C33-60D 1235468
XC14-048-230 TXV 49,500 14.70 12.50 C33-62C G61MPV-60C-090 1235490
XC14-048-230 TXV 49,500 14.50 12.20 C33-62C G61MPV-60C-091 1235492
XC14-048-230 TXV 49,500 15.00 12.50 C33-62C G61MPV-60C-110 1235491
XC14-048-230 TXV 49,500 14.70 12.20 C33-62C G61MPV-60C-111 1235493
XC14-048-230 TXV 49,500 15.20 12.70 C33-62C SL280UH090V60C 4035324
XC14-048-230 TXV 49,500 15.20 12.70 C33-62C SL280UH090XV60C 4235568
XC14-048-230 TXV 49,500 15.20 12.70 C33-62C SL280UH110V60C 4035325
XC14-048-230 TXV 49,500 15.20 12.70 C33-62C SL280UH110XV60C 4040459
XC14-048-230 TXV 49,500 14.70 12.50 C33-62C SLP98UH090V48C 4020545
XC14-048-230 TXV 49,500 14.70 12.50 C33-62C SLP98UH090V60C 4020546
XC14-048-230 TXV 49,000 14.70 12.20 C33-62C SLP98UH110V60C 4020547
XC14-048-230 TXV 49,000 15.00 12.50 C33-62D G61MPV-60D-135 1235497
XC14-048-230 TXV 48,500 15.00 12.50 C33-62D SL280UH135V60D 4035326
XC14-048-230 TXV 49,000 15.00 12.50 C33-62D SLP98UH135V60D 4020548
XC14-048-230 TXV 48,500 14.00 11.70 C33-62D 1235469
XC14-048-230 TXV 48,500 14.50 12.00 CB26UH-048 1235556
XC14-048-230 TXV 48,500 14.50 12.00 CBX26UH-048 1235564
XC14-048-230 TXV 48,500 14.70 12.50 CBX27UH-048 1235562
XC14-048-230 TXV 48,000 14.70 12.20 CBX27UH-060 1235563
XC14-048-230 TXV 49,500 14.70 12.20 CBX32M-042 1235566
XC14-048-230 TXV 48,000 14.50 12.00 CBX32M-048 1235557
XC14-048-230 TXV 48,500 14.20 12.00 CBX32M-060 1235586
XC14-048-230 TXV 48,500 14.50 12.20 CBX32MV-048 1235561
XC14-048-230 TXV 48,500 14.70 12.20 CBX32MV-060 1235587
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC14 Specifications

General

Compressor Type	Single-Stage
Refrigerant	R-410A
Energy Star Certified	Yes
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Cooling Capacity	1.5 - 5 tons
EER Rating	Up to 13.00
Warranty	10-year limited warranty on compressor, 5-year limited warranty on parts
SEER Rating	Up to 16.00
Compressor	Scroll
