Lennox XC14 User Manual

XC14 - 1.5 to 5 Ton Air Conditioner / Page 38
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC14-048-230 TXV 48,500 14.50 12.20 CBX40UHV-048 3291789
XC14-048-230 TXV 48,500 14.70 12.20 CBX40UHV-060 3291843
XC14-048-230 TXV 49,000 15.20 12.50 CH23-68 G61MPV-60D-135 1235555
XC14-048-230 TXV 48,500 14.20 11.70 CH23-68 1235520
XC14-048-230 TXV 48,000 14.20 12.00 CH33-43 G61MPV-60C-090 1235523
XC14-048-230 TXV 48,000 14.00 11.70 CH33-43 G61MPV-60C-091 1235525
XC14-048-230 TXV 48,000 14.20 12.00 CH33-43 G61MPV-60C-110 1235524
XC14-048-230 TXV 48,000 14.20 12.00 CH33-43 G61MPV-60C-111 1235526
XC14-048-230 TXV 48,500 14.50 12.00 CH33-43 SL280UH090V48B 4016690
XC14-048-230 TXV 48,000 14.50 12.20 CH33-43 SL280UH090V60C 3929234
XC14-048-230 TXV 48,500 14.50 12.00 CH33-43 SL280UH090XV48B 4038660
XC14-048-230 TXV 48,000 14.50 12.20 CH33-43 SL280UH090XV60C 4235430
XC14-048-230 TXV 47,500 14.50 12.00 CH33-43 SL280UH110V60C 3929235
XC14-048-230 TXV 47,500 14.50 12.00 CH33-43 SL280UH110XV60C 4040451
XC14-048-230 TXV 48,000 14.20 12.00 CH33-43 SLP98UH090V48C 4020549
XC14-048-230 TXV 48,000 14.20 12.00 CH33-43 SLP98UH090V60C 4020550
XC14-048-230 TXV 47,500 14.20 11.70 CH33-43 SLP98UH110V60C 4020551
XC14-048-230 TXV 47,500 13.70 11.50 CH33-43 1235514
XC14-048-230 TXV 47,000 14.00 11.50 CH33-44/48 SL280UH090V48B 4016691
XC14-048-230 TXV 47,000 14.00 11.50 CH33-44/48 SL280UH090XV48B 4038661
XC14-048-230 TXV 47,500 14.20 11.70 CH33-48 G61MPV-60C-090 1235529
XC14-048-230 TXV 47,500 14.00 11.70 CH33-48 G61MPV-60C-091 1235531
XC14-048-230 TXV 47,500 14.20 12.00 CH33-48 G61MPV-60C-110 1235530
XC14-048-230 TXV 47,500 14.20 11.70 CH33-48 G61MPV-60C-111 1235532
XC14-048-230 TXV 47,500 14.50 12.00 CH33-48 SL280UH090V60C 3929236
XC14-048-230 TXV 47,500 14.50 12.00 CH33-48 SL280UH090XV60C 4235431
XC14-048-230 TXV 47,500 14.20 12.00 CH33-48 SL280UH110V60C 3929237
XC14-048-230 TXV 47,500 14.20 12.00 CH33-48 SL280UH110XV60C 4040452
XC14-048-230 TXV 47,500 14.00 11.70 CH33-48 SLP98UH090V48C 4020552
XC14-048-230 TXV 47,500 14.00 11.70 CH33-48 SLP98UH090V60C 4020553
XC14-048-230 TXV 47,500 14.00 11.70 CH33-48 SLP98UH110V60C 4020554
XC14-048-230 TXV 47,500 13.70 11.50 CH33-48 1235515
XC14-048-230 TXV 48,500 14.50 12.00 CH33-49 G61MPV-60C-090 1235535
XC14-048-230 TXV 48,500 14.20 12.00 CH33-49 G61MPV-60C-091 1235537
XC14-048-230 TXV 48,500 14.50 12.20 CH33-49 G61MPV-60C-110 1235536
XC14-048-230 TXV 48,500 14.50 12.00 CH33-49 G61MPV-60C-111 1235538
XC14-048-230 TXV 48,500 14.70 12.20 CH33-49 SL280UH090V60C 3929238
XC14-048-230 TXV 48,500 14.70 12.20 CH33-49 SL280UH090XV60C 4235432
XC14-048-230 TXV 48,500 14.70 12.20 CH33-49 SL280UH110V60C 3929239
XC14-048-230 TXV 48,500 14.70 12.20 CH33-49 SL280UH110XV60C 4040453
XC14-048-230 TXV 48,500 14.50 12.00 CH33-49 SLP98UH090V48C 4020555
XC14-048-230 TXV 48,500 14.50 12.00 CH33-49 SLP98UH090V60C 4020556
XC14-048-230 TXV 48,500 14.50 12.00 CH33-49 SLP98UH110V60C 4020557
XC14-048-230 TXV 48,000 14.00 11.70 CH33-49 1235516
XC14-048-230 TXV 48,000 14.20 12.00 CH33-50/60C G61MPV-60C-090 1235541
XC14-048-230 TXV 48,000 14.20 11.70 CH33-50/60C G61MPV-60C-091 1235543
XC14-048-230 TXV 48,500 14.50 12.20 CH33-50/60C G61MPV-60C-110 1235542
XC14-048-230 TXV 48,500 14.70 12.20 CH33-50/60C SL280UH090V60C 3929240
XC14-048-230 TXV 48,500 14.70 12.20 CH33-50/60C SL280UH090XV60C 4235433
XC14-048-230 TXV 48,000 14.50 12.20 CH33-50/60C SL280UH110V60C 3929241
XC14-048-230 TXV 48,000 14.50 12.20 CH33-50/60C SL280UH110XV60C 4040454
XC14-048-230 TXV 48,000 14.20 12.00 CH33-50/60C SLP98UH090V48C 4020558
XC14-048-230 TXV 48,000 14.20 12.00 CH33-50/60C SLP98UH090V60C 4020559
XC14-048-230 TXV 48,000 14.20 12.00 CH33-50/60C SLP98UH110V60C 4020560
XC14-048-230 TXV 48,000 14.00 11.70 CH33-50/60C 1235517
XC14-048-230 TXV 48,000 14.70 12.20 CH33-60D G61MPV-60D-135 1235545
XC14-048-230 TXV 47,500 14.70 12.20 CH33-60D SL280UH135V60D 3929242
XC14-048-230 TXV 48,000 14.70 12.20 CH33-60D SLP98UH135V60D 4020561
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC14 Specifications

General

Compressor Type	Single-Stage
Refrigerant	R-410A
Energy Star Certified	Yes
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Cooling Capacity	1.5 - 5 tons
EER Rating	Up to 13.00
Warranty	10-year limited warranty on compressor, 5-year limited warranty on parts
SEER Rating	Up to 16.00
Compressor	Scroll
