Lennox XC14 User Manual

XC14 - 1.5 to 5 Ton Air Conditioner / Page 39
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC14-048-230 TXV 47,500 13.70 11.50 CH33-60D 1235518
XC14-048-230 TXV 48,500 14.50 12.20 CH33-62D G61MPV-60C-090 1235550
XC14-048-230 TXV 48,500 14.20 12.00 CH33-62D G61MPV-60C-091 1235551
XC14-048-230 TXV 48,500 14.70 12.20 CH33-62D G61MPV-60C-110 1235552
XC14-048-230 TXV 48,500 14.50 12.20 CH33-62D G61MPV-60C-111 1235553
XC14-048-230 TXV 48,500 14.70 12.20 CH33-62D G61MPV-60D-135 1235547
XC14-048-230 TXV 48,000 15.00 12.50 CH33-62D SL280UH135V60D 3929243
XC14-048-230 TXV 48,500 14.70 12.20 CH33-62D SLP98UH135V60D 4020562
XC14-048-230 TXV 48,000 14.00 11.70 CH33-62D 1235519
XC14-048-230 TXV 45,500 13.70 11.20 CR33-48 G61MPV-60C-090 1235502
XC14-048-230 TXV 45,500 13.20 11.20 CR33-48 G61MPV-60C-091 1235504
XC14-048-230 TXV 45,500 13.70 11.50 CR33-48 G61MPV-60C-110 1235503
XC14-048-230 TXV 46,000 13.50 11.50 CR33-48 G61MPV-60C-111 1235505
XC14-048-230 TXV 46,000 14.00 11.70 CR33-48 SL280DF090V60C 3929244
XC14-048-230 TXV 46,000 14.00 11.70 CR33-48 SL280DF110V60C 3929245
XC14-048-230 TXV 45,500 13.50 11.20 CR33-48 SLP98DF090V48C 4020580
XC14-048-230 TXV 45,500 13.50 11.20 CR33-48 SLP98DF090V60C 4020581
XC14-048-230 TXV 45,500 13.50 11.20 CR33-48 SLP98DF110V60C 4020582
XC14-048-230 TXV 47,500 14.20 12.00 CR33-50/60 G61MPV-60C-090 1235508
XC14-048-230 TXV 47,500 14.00 11.70 CR33-50/60 G61MPV-60C-091 1235510
XC14-048-230 TXV 47,500 14.20 12.00 CR33-50/60 G61MPV-60C-110 1235509
XC14-048-230 TXV 47,500 14.20 12.00 CR33-50/60 G61MPV-60C-111 1235511
XC14-048-230 TXV 47,500 14.50 12.20 CR33-50/60 SL280DF090V60C 3929246
XC14-048-230 TXV 47,500 14.70 12.20 CR33-50/60 SL280DF110V60C 3929247
XC14-048-230 TXV 47,500 14.00 11.70 CR33-50/60 SLP98DF090V48C 4020583
XC14-048-230 TXV 47,500 14.20 11.70 CR33-50/60 SLP98DF090V60C 4020584
XC14-048-230 TXV 47,000 14.20 11.70 CR33-50/60 SLP98DF110V60C 4020585
XC14-048-230 TXV 47,000 13.70 11.50 CR33-50/60 1235498
XC14-048-230 TXV 47,500 14.50 12.20 CR33-60 G61MPV-60D-135 1235513
XC14-048-230 TXV 47,000 13.70 11.50 CR33-60 1235499
XC14-048-230 TXV 48,000 14.20 12.00 CX34-43 G61MPV-60C-090 1235445
XC14-048-230 TXV 48,000 14.00 11.70 CX34-43 G61MPV-60C-091 1235447
XC14-048-230 TXV 48,000 14.50 12.20 CX34-43 G61MPV-60C-110 1235446
XC14-048-230 TXV 48,000 14.20 12.00 CX34-43 G61MPV-60C-111 1235448
XC14-048-230 TXV 47,500 14.20 11.70 CX34-43 SL280UH090V48B 4016688
XC14-048-230 TXV 47,500 14.70 12.20 CX34-43 SL280UH090V60C 3929222
XC14-048-230 TXV 47,500 14.20 11.70 CX34-43 SL280UH090XV48B 4038658
XC14-048-230 TXV 47,500 14.70 12.20 CX34-43 SL280UH090XV60C 4235425
XC14-048-230 TXV 47,500 14.50 12.20 CX34-43 SL280UH110V60C 3929223
XC14-048-230 TXV 47,500 14.50 12.20 CX34-43 SL280UH110XV60C 4040446
XC14-048-230 TXV 47,500 14.20 12.00 CX34-43 SLP98UH090V48C 4020563
XC14-048-230 TXV 48,000 14.20 12.00 CX34-43 SLP98UH090V60C 4020564
XC14-048-230 TXV 47,500 14.20 12.00 CX34-43 SLP98UH110V60C 4020565
XC14-048-230 TXV 47,500 13.70 11.50 CX34-43 1235433
XC14-048-230 TXV 47,000 14.00 11.70 CX34-44/48 G61MPV-60C-090 1235439
XC14-048-230 TXV 47,000 13.70 11.50 CX34-44/48 G61MPV-60C-091 1235441
XC14-048-230 TXV 47,000 14.00 11.70 CX34-44/48 G61MPV-60C-110 1235440
XC14-048-230 TXV 47,000 14.00 11.70 CX34-44/48 G61MPV-60C-111 1235442
XC14-048-230 TXV 46,500 14.00 11.50 CX34-44/48 SL280UH090V48B 4016689
XC14-048-230 TXV 47,000 14.20 11.70 CX34-44/48 SL280UH090V60C 3929224
XC14-048-230 TXV 46,500 14.00 11.50 CX34-44/48 SL280UH090XV48B 4038659
XC14-048-230 TXV 47,000 14.20 11.70 CX34-44/48 SL280UH090XV60C 4235426
XC14-048-230 TXV 47,000 14.20 11.70 CX34-44/48 SL280UH110V60C 3929225
XC14-048-230 TXV 47,000 14.20 11.70 CX34-44/48 SL280UH110XV60C 4040447
XC14-048-230 TXV 46,500 14.00 11.50 CX34-44/48 SLP98UH090V48C 4020566
XC14-048-230 TXV 47,000 14.00 11.70 CX34-44/48 SLP98UH090V60C 4020567
XC14-048-230 TXV 46,500 14.00 11.50 CX34-44/48 SLP98UH110V60C 4020568
XC14-048-230 TXV 46,500 13.50 11.20 CX34-44/48 1235432
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC14 Specifications

General

Compressor Type	Single-Stage
Refrigerant	R-410A
Energy Star Certified	Yes
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Cooling Capacity	1.5 - 5 tons
EER Rating	Up to 13.00
Warranty	10-year limited warranty on compressor, 5-year limited warranty on parts
SEER Rating	Up to 16.00
Compressor	Scroll
