Lennox XC14 User Manual

XC14 - 1.5 to 5 Ton Air Conditioner / Page 40
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC14-048-230 TXV 48,500 14.70 12.20 CX34-49 G61MPV-60C-090 1235451
XC14-048-230 TXV 48,500 14.20 12.00 CX34-49 G61MPV-60C-091 1235453
XC14-048-230 TXV 48,500 14.70 12.20 CX34-49 G61MPV-60C-110 1235452
XC14-048-230 TXV 48,500 14.50 12.20 CX34-49 G61MPV-60C-111 1235454
XC14-048-230 TXV 48,500 14.70 12.20 CX34-49 SL280UH090V60C 3929226
XC14-048-230 TXV 48,500 14.70 12.20 CX34-49 SL280UH090XV60C 4235427
XC14-048-230 TXV 48,000 14.70 12.20 CX34-49 SL280UH110V60C 3929227
XC14-048-230 TXV 48,000 14.70 12.20 CX34-49 SL280UH110XV60C 4040448
XC14-048-230 TXV 48,500 14.50 12.20 CX34-49 SLP98UH090V48C 4020569
XC14-048-230 TXV 48,500 14.50 12.20 CX34-49 SLP98UH090V60C 4020570
XC14-048-230 TXV 48,500 14.50 12.20 CX34-49 SLP98UH110V60C 4020571
XC14-048-230 TXV 48,500 14.00 11.70 CX34-49 1235434
XC14-048-230 TXV 47,500 14.20 11.70 CX34-50/60C G61MPV-60C-090 1235575
XC14-048-230 TXV 47,500 14.00 11.70 CX34-50/60C G61MPV-60C-091 1235577
XC14-048-230 TXV 47,500 14.20 12.00 CX34-50/60C G61MPV-60C-110 1235576
XC14-048-230 TXV 47,500 14.00 11.70 CX34-50/60C G61MPV-60C-111 1235578
XC14-048-230 TXV 47,500 14.20 12.00 CX34-50/60C SL280UH090V60C 3929228
XC14-048-230 TXV 47,500 14.20 12.00 CX34-50/60C SL280UH090XV60C 4235428
XC14-048-230 TXV 47,500 14.20 12.00 CX34-50/60C SL280UH110V60C 3929229
XC14-048-230 TXV 47,500 14.20 12.00 CX34-50/60C SL280UH110XV60C 4040449
XC14-048-230 TXV 47,500 14.00 11.70 CX34-50/60C SLP98UH090V48C 4020572
XC14-048-230 TXV 47,500 14.00 11.70 CX34-50/60C SLP98UH090V60C 4020573
XC14-048-230 TXV 47,500 14.00 11.70 CX34-50/60C SLP98UH110V60C 4020574
XC14-048-230 TXV 47,000 13.70 11.50 CX34-50/60C 1235572
XC14-048-230 TXV 48,500 14.70 12.20 CX34-60D G61MPV-60D-135 1235462
XC14-048-230 TXV 48,000 15.00 12.50 CX34-60D SL280UH135V60D 3929230
XC14-048-230 TXV 48,500 14.70 12.20 CX34-60D SLP98UH135V60D 4020575
XC14-048-230 TXV 48,000 14.00 11.70 CX34-60D 1235435
XC14-048-230 TXV 49,500 14.70 12.50 CX34-62C G61MPV-60C-090 1235457
XC14-048-230 TXV 49,500 14.50 12.20 CX34-62C G61MPV-60C-091 1235459
XC14-048-230 TXV 49,500 15.00 12.50 CX34-62C G61MPV-60C-110 1235458
XC14-048-230 TXV 49,500 14.70 12.20 CX34-62C G61MPV-60C-111 1235460
XC14-048-230 TXV 49,500 15.20 12.70 CX34-62C SL280UH090V60C 3929231
XC14-048-230 TXV 49,500 15.20 12.70 CX34-62C SL280UH090XV60C 4235429
XC14-048-230 TXV 49,500 15.20 12.70 CX34-62C SL280UH110V60C 3929232
XC14-048-230 TXV 49,500 15.20 12.70 CX34-62C SL280UH110XV60C 4040450
XC14-048-230 TXV 49,500 14.70 12.50 CX34-62C SLP98UH090V48C 4020576
XC14-048-230 TXV 49,500 14.70 12.50 CX34-62C SLP98UH090V60C 4020577
XC14-048-230 TXV 49,000 14.70 12.20 CX34-62C SLP98UH110V60C 4020578
XC14-048-230 TXV 49,000 14.20 12.00 CX34-62C 1234801
XC14-048-230 TXV 49,000 15.00 12.50 CX34-62D G61MPV-60D-135 1235464
XC14-048-230 TXV 48,500 15.00 12.50 CX34-62D SL280UH135V60D 3929233
XC14-048-230 TXV 49,000 15.00 12.50 CX34-62D SLP98UH135V60D 4020579
XC14-048-230 TXV 48,500 14.00 11.70 CX34-62D 1235436
XC14-060-230 RFC 56,000 13.70 11.70 C33-49 G61MPV-60C-090 1237140
XC14-060-230 RFC 56,000 14.00 11.70 C33-49 G61MPV-60C-110 1237141
XC14-060-230 RFC 56,500 13.70 11.70 C33-49 1237135
XC14-060-230 RFC 55,500 13.50 11.50 C33-50/60C G61MPV-60C-090 1237144
XC14-060-230 RFC 55,500 13.50 11.70 C33-50/60C G61MPV-60C-110 1237145
XC14-060-230 RFC 55,500 13.50 11.50 C33-50/60C 1237136
XC14-060-230 RFC 56,500 14.20 12.00 C33-60D G61MPV-60D-135 1237147
XC14-060-230 RFC 56,000 13.70 11.50 C33-60D 1237137
XC14-060-230 RFC 57,000 14.00 11.70 C33-62C G61MPV-60C-090 1237150
XC14-060-230 RFC 57,500 14.20 12.00 C33-62C G61MPV-60C-110 1237151
XC14-060-230 RFC 57,500 14.00 11.70 C33-62C 1237134
XC14-060-230 RFC 57,000 14.20 12.20 C33-62D G61MPV-60D-135 1237181
XC14-060-230 RFC 56,500 13.70 11.70 C33-62D 1237179
XC14-060-230 RFC 57,000 14.20 12.20 CH23-68 G61MPV-60D-135 1237175
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC14 Specifications

General

Compressor Type	Single-Stage
Refrigerant	R-410A
Energy Star Certified	Yes
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Cooling Capacity	1.5 - 5 tons
EER Rating	Up to 13.00
Warranty	10-year limited warranty on compressor, 5-year limited warranty on parts
SEER Rating	Up to 16.00
Compressor	Scroll
