Lenord + Bauer 6 Specifications
GEL 2442 31
English
6 Specifications
Electrical data
Output level 1 V
pp
difference signal
Output signal two 90° phase-shifted sinusoidal signals
and their inverse signals, short circuit
proof; optionally with reference pulse.
Output frequency 0... 200 kHz at a line capacity 5 nF
Offset (static) ± 20 mV
Amplitude tolerance - 20% to + 10%
Amplitude ratio V
TR1
/V
TR2
0.9 .to 1.1
Supply voltage V
S
5 V DC ± 5 %
Power consumption without load ≤ 0.3 W
Mechanical data
Admissible air gap 0.15 mm ± 0.02 mm with module 0.3
0.20 mm ± 0.03 mm with module 0.5
Width of the target wheel ≥ 4.0 mm
Material of the target wheel Ferromagnetic steel
Max. admissible cable length 100 m (observe the voltage drop on the
power line)
Working temperature - 30 °C to + 85 °C
Operating and storage temperature - 40 °C to + 120 °C
Protection class IP 68
Electromagnetic compatibility EN 61000-6-1 to 4
(1)
Insulation strength 500 V, according to EN 60439-1
Vibration resistance 200 m/s
2
according to DIN EN 60068-2-6
Shock resistance 2000 m/s
2
according to DIN EN
600068-2-27
Weight 30 g
Housing Polyphenylene sulfide(PPS), glassfibre
reinforced
Connection 9-core cable, wire profile 0.15 mm
2
O.D. 5
–0.3 mm
mm, min. bending radius
25 mm.
Seperate screen connection line for near-
sensor earthing (e.g. using one fixing
screw)
(1)
The normative limit values are met if mounting and connection jobs are carried out properly. Coaxial earthing of
the MiniCoder connection cable, e.g. on the free cable end will improve noise.
