Lenovo B575e - 1040 Optical Drive

Removetheharddiskdrivebracketinthedirectionshownbythearrow2.
2
1040Opticaldrive
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage44
•“1020Bottomslotcover”onpage44
Removalstepsoftheopticaldrive
Removethescrew1,insertascrewdriverintothescrewholeandpushtheopticaldriveinthedirection
shownbythearrow2.Pulltheopticaldriveout.
1
StepScrew(quantity)Color
Torque
1
M2×3mm,at-head,nylon-coated(1)
Black
1.6kgf-cm
Chapter7.RemovingandreplacingaFRU47
