Chapter8.Locations
Thischapterintroducesthelocationsofthecomputerhardwarecomponents.
Frontview
1
2
4
5
6
7
13
14
15
4
16
12
8
9
10
11
3
Figure1.LenovoB575efrontview
1Integratedcamera(onsomemodels)
9Microphonejack
2Wirelessantennas(onsomemodels)
10Headphonejack
3Statusindicators
1
11Mediacardreaderslot
4Speakers
12Touchpad
5Ethernetconnector
13Statusindicators
2
6USBconnector
14Built-inmicrophone
7Opticaldrive
15Powerbutton
8USBconnector
16Recoverybutton
1
and
2
Forthedescriptionoftheindicators,see“Statusindicators”onpage38.
©CopyrightLenovo2012
