Detachtheconnector9andremovethesystemboardinthedirectionshownbythearrow10.
9
10
1140LCDunit
Foraccess,removetheseFRUsinorder:
“1010Batterypack”onpage44
“1020Bottomslotcover”onpage44
“1030Harddiskdrive”onpage45
“1040Opticaldrive”onpage47
“1050Memorymodules”onpage48
“1060PCIExpressMiniCardforwirelessLAN”onpage49
“1070Backupbattery”onpage50
“1080Keyboard”onpage51
“1090Keyboardbezel”onpage54
“1130Systemboardassembly”onpage63
Chapter7.RemovingandreplacingaFRU65
