Chapter 1. Getting to know your computer
Bottom view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Battery latch -
manual
The manual battery latch is used to keep the battery pack
secured in place.
Louvers
Allow air to enter the computer for cooling.
Battery latch -
spring loaded
The spring-loaded battery latch keeps the battery pack
secured in place.
Battery pack
For details, see “Using AC adapter and battery” on page
8.
Speakers
The stereo speakers provide rich and powerful sound.
a c d
e
b
a
b
c
d
e
