RemovalstepsoftheLCDbezelassembly
StepScrewcapScrew(quantity)Color
Torque
1
M2×L3mm,flat-head,nylon-coated(2)
Black0.181Nm
(1.85kgf-cm)
Wheninstalling:Ensurethatallthelatchesareattachedfirmly.
2020LCDpanelandLCDcable
Foraccess,removetheseFRUsinorder:
•“1010Bottomcover”onpage60
•“1020Battery”onpage61
•“1030M.2solid-statedrive”onpage63
•“1040WirelessLANcard”onpage64
•“1050Memorymodule”onpage64
•“1060Coin-cellbattery”onpage65
•“1070Keyboard”onpage65
•“1080Keyboardbezelassemblyandmedia-card-readerboard”onpage67
•“1090Systemboardassembly,dc-inconnector,andthermalfan”onpage70
Chapter8.RemovingorreplacingaFRU77
