Lenovo ThinkPad X61 Tablet User Manual

LCD-related symptoms
Important: The TFT LCD for the notebook computer contains many thin-film
transistors (TFTs). The presence of a small number of dots that are
missing, discolored, or always lighted is characteristic of TFT LCD
technology, but excessive pixel problems can cause viewing concerns.
The LCD should be replaced if the number of missing, discolored, or
lighted dots in any background is as follows:
Minimum quantity of defective pixels required for LCD replacement on June 2006 or later
manufactured ThinkPad
LCD resolution Bright dots Dark dots Bright and dark dots
XGA, WXGA 5 6 6
WXGA+, SXGA+,
WSXGA+
5 8 10
UXGA, WUXGA,
QXGA
5 13 13
Notes:
1. Lenovo will not provide replacement if the LCD is within specification as we
cannot guarantee that any replacement LCD will have zero pixel defects.
2. A bright dot means a pixel is always on (white or color.)
3. A dark dot means a pixel is always off (black color.)
4. One pixel consists of R, G, B sub-pixels.
Symptom or error FRU or action, in sequence
No beep, power-on indicator on, and a
blank LCD during POST.
System board.
v LCD backlight not working.
v LCD too dark.
v LCD brightness cannot be adjusted.
v LCD contrast cannot be adjusted.
1. Reseat the LCD connectors.
2. LCD assembly.
3. System board.
v LCD screen unreadable.
v Characters missing pixels.
v Screen abnormal.
v Wrong color displayed.
1. See important note for “LCD-related
symptoms.”
2. Reseat all LCD connectors.
3. LCD assembly.
4. System board.
Horizontal or vertical lines displayed on
LCD.
LCD assembly.
Symptom-to-FRU index
ThinkPad X60 Tablet and X61 Tablet 49

Lenovo ThinkPad X61 Tablet Specifications

General

Bus type	FSB
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor model	L7500
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo L7000 Series
Processor socket	Socket 479
Processor codename	Merom
Processing Die size	143 mm²
Processor frequency	1.6 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	17 W
CPU multiplier (bus/core ratio)	8
Number of Processing Die Transistors	291 M
Memory slots	2x SO-DIMM
Maximum internal memory	4 GB
HDD capacity	120 GB
HDD interface	SATA
Compatible memory cards	SD
Display diagonal	12.1 \
Display resolution	1024 x 768 pixels
Native aspect ratio	4:3
Modem speed	56 Kbit/s
Graphics card	GMA X3100
Internal modem	Yes
Charging port type	DC-in jack
USB 2.0 ports quantity	3
CardBus PCMCIA slot type	Type II
Ethernet LAN (RJ-45) ports	1
Battery life (max)	2.9 h
Number of battery cells	4
Audio system	AD1984 Codec
Networking features	Gigabit Ethernet
Bundled software	Adobe Acrobat Reader, Sun JRE, ThinkVantage Productivity Center, ThinkVantage Access Connections, ThinkVantage Client Security Solution, ThinkVantage System Update, Norton Internet Security 2007 (OEM), Diskeeper 9.0 Home Edition, ThinkVantage Rescue and Recovery, PC-Doctor diagnostics
Processor ARK ID	29757
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	244 mm
Width	274 mm
Height	33 mm
Weight	1800 g
