Lenovo ThinkPad X61 Tablet User Manual

About this manual
This manual contains service and reference information for ThinkPad
®
X60 Tablet
and X61 Tablet (MT 6363, 6364, 6365, 6366, 6367, 6368, 7762, 7763, 7764, 7767, 7768,
and 7769) products. Use this manual along with the advanced diagnostic tests to
troubleshoot problems.
The manual is divided into sections as follows:
v The common sections provide general information, guidelines, and safety
information required in servicing computers.
v The product-specific section includes service, reference, and product-specific
parts information.
Important
This manual is intended for trained service personnel who are familiar with
ThinkPad products. Use this manual along with the advanced diagnostic tests
to troubleshoot problems effectively.
Before servicing a ThinkPad product, be sure to review the safety information
under “Safety notices: multilingual translations” on page 7, “Safety
information” on page 13, and “Laser compliance statement” on page 17.
© Copyright Lenovo 2007 1

Lenovo ThinkPad X61 Tablet Specifications

General

Bus type	FSB
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor model	L7500
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo L7000 Series
Processor socket	Socket 479
Processor codename	Merom
Processing Die size	143 mm²
Processor frequency	1.6 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	17 W
CPU multiplier (bus/core ratio)	8
Number of Processing Die Transistors	291 M
Memory slots	2x SO-DIMM
Maximum internal memory	4 GB
HDD capacity	120 GB
HDD interface	SATA
Compatible memory cards	SD
Display diagonal	12.1 \
Display resolution	1024 x 768 pixels
Native aspect ratio	4:3
Modem speed	56 Kbit/s
Graphics card	GMA X3100
Internal modem	Yes
Charging port type	DC-in jack
USB 2.0 ports quantity	3
CardBus PCMCIA slot type	Type II
Ethernet LAN (RJ-45) ports	1
Battery life (max)	2.9 h
Number of battery cells	4
Audio system	AD1984 Codec
Networking features	Gigabit Ethernet
Bundled software	Adobe Acrobat Reader, Sun JRE, ThinkVantage Productivity Center, ThinkVantage Access Connections, ThinkVantage Client Security Solution, ThinkVantage System Update, Norton Internet Security 2007 (OEM), Diskeeper 9.0 Home Edition, ThinkVantage Rescue and Recovery, PC-Doctor diagnostics
Processor ARK ID	29757
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	244 mm
Width	274 mm
Height	33 mm
Weight	1800 g
