Lenovo ThinkPad X61 Tablet User Manual

Removing and replacing a FRU
This section presents directions and drawings for use in removing and replacing a
FRU. Be sure to observe the following general rules:
1. Do not try to service any computer unless you have been trained and certified.
An untrained person runs the risk of damaging parts.
2. Before replacing any FRU, review “FRU replacement notices” on page 51.
3. Begin by removing any FRUs that have to be removed before the failing FRU.
Any such FRUs are listed at the top of the page. Remove them in the order in
which they are listed.
4. Follow the correct sequence in the steps for removing the FRU, as given in the
drawings by the numbers in square callouts.
5. When turning a screw to replace a FRU, turn it in the direction as given by the
arrow in the drawing.
6. When removing the FRU, move it in the direction as given by the arrow in the
drawing.
7. To put the new FRU in place, reverse the removal procedure and follow any
notes that pertain to replacement. For information about connecting and
arranging internal cables, see “Locations” on page 103.
8. When replacing a FRU, use the correct screw as shown in the procedures.
DANGER
Attention: After replacing a FRU, do not turn on the computer until you have
made sure that all screws, springs, and other small parts are in place and none are
loose inside the computer. Verify this by shaking the computer gently and listening
for rattling sounds. Metallic parts or metal flakes can cause electrical short circuits.
Attention: The system board is sensitive to, and can be damaged by, electrostatic
discharge. Before touching it, establish personal grounding by touching a ground
point with one hand or by using an electrostatic discharge (ESD) strap (P/N
6405959).
Before removing any FRU, turn off the computer, unplug all power cords from
electrical outlets, remove the battery pack, and then disconnect any interconnecting
cables.
Removing and replacing a FRU
54 MT 6363, 6364, 6365, 6366, 6367, 6368, 7762, 7763, 7764, 7767, 7768, and 7769

Lenovo ThinkPad X61 Tablet Specifications

General

Bus type	FSB
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor model	L7500
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo L7000 Series
Processor socket	Socket 479
Processor codename	Merom
Processing Die size	143 mm²
Processor frequency	1.6 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	17 W
CPU multiplier (bus/core ratio)	8
Number of Processing Die Transistors	291 M
Memory slots	2x SO-DIMM
Maximum internal memory	4 GB
HDD capacity	120 GB
HDD interface	SATA
Compatible memory cards	SD
Display diagonal	12.1 \
Display resolution	1024 x 768 pixels
Native aspect ratio	4:3
Modem speed	56 Kbit/s
Graphics card	GMA X3100
Internal modem	Yes
Charging port type	DC-in jack
USB 2.0 ports quantity	3
CardBus PCMCIA slot type	Type II
Ethernet LAN (RJ-45) ports	1
Battery life (max)	2.9 h
Number of battery cells	4
Audio system	AD1984 Codec
Networking features	Gigabit Ethernet
Bundled software	Adobe Acrobat Reader, Sun JRE, ThinkVantage Productivity Center, ThinkVantage Access Connections, ThinkVantage Client Security Solution, ThinkVantage System Update, Norton Internet Security 2007 (OEM), Diskeeper 9.0 Home Edition, ThinkVantage Rescue and Recovery, PC-Doctor diagnostics
Processor ARK ID	29757
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	244 mm
Width	274 mm
Height	33 mm
Weight	1800 g
