8.Carefullypositionthenewfrontpanelboardonthechassissothatthefrontcontrols,connectors,
andLEDsarethroughthecorrespondingholesinthefrontbezelandthetwoscrewholesinthenew
frontpanelboardarealignedwiththecorrespondingmountingstudsonthechassis.Then,installthe
screwstosecurethefrontpanelboardinplace.
Figure124.Installingthefrontpanelboardforservermodelswitheight3.5-inchharddiskdrivebays
9.ConnectthefrontpanelcableandthefrontpanelUSBcabletotherearofthenewfrontpanelboard.
10.Ifyouareinstructedtoreturntheoldfrontpanelboard,followallpackaginginstructionsanduseany
packagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage182.
Replacingthefrontpanelboardforservermodelswith2.5-inchharddiskdrivebays
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage81.
Toreplacethefrontpanelboardforservermodelswith2.5-inchharddiskdrivebays,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Iftheserverisinstalledinarackcabinet,removetheserverfromtherackcabinetandplaceitonaflat,
clean,andstatic-protectivesurface.SeetheRackInstallationInstructionsthatcomeswiththeserver.
3.Removetheservercover.See“Removingtheservercover”onpage83.
4.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage85.
5.Removethecoolingshroud.See“Removingandreinstallingthecoolingshroud”onpage91.
6.Locatethefrontpanelboard.See“Componentsofservermodelswith2.5-inchharddiskdrivebays”
onpage34
.
7.Removetheleftcage.See“Removingandreinstallingtheleftcage”onpage93.
Chapter6.Installing,removing,orreplacinghardware165
