Componentsofservermodelswith2.5-inchharddiskdrivebays
Figure22.Componentsofservermodelswith2.5-inchharddiskdrivebays
1Coolingshroud13Slimopticaldrive(availableinsomemodels)
2Powersupplycoolingshroud
14Diagnosticmodule(variesbymodel)
3Risercardassembly2
15Rackhandle(left)
4Oneortwohot-swapredundantpowersupplies
16Frontpanelboard
5PCIExpresscards(availableinsomemodels)17Systemfans(4)
6Heatsinkswithmicroprocessorsunderneath
18CPU1DIMMs(varybymodel)
7Backplanesforservermodelswith2.5-inchhard
diskdrivebays
19CPU2DIMMs(varybymodel)
8Rackhandle(right)20Systemboard
92.5-inchharddiskdrivearea(rightcage)21Systemboardbattery
102.5-inchharddiskdrivearea(middlecage)22PCIExpresscards(availableinsomemodels)
11Pull-outinformationcard
23Risercardassembly1
12VGADB-15connector
CRUidentification
CRUsarepartsthatcanbeupgradedorreplacedbythecustomer.IfaCRUisdeterminedtobedefective
duringthewarrantyperiod,areplacementCRUwillbeprovidedtothecustomer.Customersareresponsible
forinstallingtheself-serviceCRUsforthisproduct.Customersalsocaninstalloptional-serviceCRUs,which
34ThinkServerRD430HardwareMaintenanceManual
