PowerstatusLED
Color
Description
OnGreen
Theserverison.
Off
None
Theserverisoff.
Blinking
GreenTheserverisinACPIS1mode,whichalsoisknown
asPowerOnSuspend(POS)mode.Inthismode,
themicroprocessorsarenotworkingwhileother
hardwaredevicesarestillworking.
5IDbuttonwithIDLED
WhenyoupresstheIDbutton,theIDLEDsonboththefrontandrearoftheserverarelittohelpyoulocate
theserveramongotherservers.YoualsocanturnontheIDLEDsusingaremotemanagementprogram
forserverpresencedetection.
IDLED
Color
Description
On
Blue
Theserverisidentified.
Off
None
TheIDLEDisnotinuseortheserverisnotidentified.
6NIC1statusLED
7NIC2statusLED
TheNIC1statusLEDindicatestheLANstatusfortheEthernetconnector1ontherearoftheserver.
TheNIC2statusLEDindicatestheLANstatusfortheEthernetconnector2ontherearoftheserver.
NICstatusLEDColor
Description
OnGreen
TheserverisconnectedtoaLAN.
Off
None
TheserverisdisconnectedfromaLAN.
Blinking
Green
TheLANisconnectedandactive.
8SystemerrorLED
ThesystemerrorLEDhelpsyoutodetermineifthereareanysystemerrors.
SystemerrorLEDColor
Description
On
Amber
Oneormoresystemerrorshaveoccurredandthe
systemislikelytofail.
Off
None
Theserverisoffortheserverisonandisworking
correctly.
Chapter3.Productoverview19
