Frontviewofservermodelswith2.5-inchharddiskdrivebays
Thefollowingillustrationshowsthefrontviewofservermodelswith2.5-inchharddiskdrivebays.
Figure9.Frontviewofservermodelswith2.5-inchharddiskdrivebays
12.5-inchharddiskdrivearea(rightcage)5Rackhandle(left)
22.5-inchharddiskdrivearea(middlecage)6Diagnosticpanel(variesbymodel)
3Pull-outinformationcard
7Frontpanel
4Slimopticaldrive(availableinsomemodels)8Rackhandle(right)
12.5-inchharddiskdrivearea(rightcage)
22.5-inchharddiskdrivearea(middlecage)
Thefrontofservermodelswith2.5-inchharddiskdrivebaysconsistsofthreecages:
•Theleftcageconsistsofthefrontpanelboard,thefrontVGADB-15connector,thediagnosticmodule,
thepull-outinformationcard,andtheslimopticaldrivebay.
•Themiddlecageconsistsofthenumber0tonumber7harddiskdrivebays.Thereiseithera2.5-inch
hot-swapharddiskdriveora2.5-inchdummyharddiskdrivetrayinstalledineachbay.
•Therightcageconsistsofthenumber8tonumber15harddiskdrivebays.Thereiseithera2.5-inch
hot-swapharddiskdriveora2.5-inchdummyharddiskdrivetrayinstalledineachbay.Iftheserver
supportsuptoeightharddiskdrives,therewillbeanEMI-protectivepanelthatcoverstherightcage
asawhole.
Figure10.RightcagewithanEMI-protectivepanel
Note:Theharddiskdrivebaynumber(0-15)ismarkedaboveeach2.5-inchharddiskdrivebayonthe
frontbezel.
3Pull-outinformationcard
Themachinetype,model,andserialnumberlabeloftheserverisattachedonthepull-outinformationcard.
See“Machinetype,model,andserialnumberlabel”onpage13
.
