system uptime.
The server offers redundant hot-swap power supplies and hot-swap redundant fans to provide
availability for business-critical applications.
The new diagnostics LCD display panel simplifies servicing, speeds up problem resolution, and
helps improve system availability.
Solid-state drives (SSDs) offer significantly better reliability than mechanical HDDs for greater
uptime.
Built-in ThinkServer System Manager TSM continuously monitors system parameters and triggers
alerts to minimize downtime.
One- or three-year customer replaceable unit and onsite limited warranty (depending on model),
next business day 9x5. Optional service upgrades are available.
Manageability and security
Powerful systems management features simplify local and remote management of the RD450:
Support for Lenovo XClarity Administrator, providing autodiscovery, inventory tracking, monitoring,
and call home capabilities.
Includes ThinkServer System Manager (TSM) to monitor server availability and perform remote
management. Optional TSM Premium added remote control and remote media.
Support for Lenovo XClarity Energy Manager which captures real-time power and temperature data
from the server and provides automated controls to lower energy costs.
Embedded ThinkServer Deployment Manager (TDM) provides a complete set of provisioning
capabilities from a single interface, automating many of the tasks associated with server
provisioning.
An optional Trusted Platform Modules (TPM) enables advanced cryptographic functionality such as
digital signatures and Windows BitLocker encryption, a Windows data protection feature.
Intel Execute Disable Bit functionality can help prevent certain classes of malicious buffer overflow
attacks when combined with a supporting operating system.
Intel Trusted Execution Technology provides enhanced security through hardware-based resistance
to malicious software attacks, allowing an application to run in its own isolated space, protected
from all other software running on a system.
Energy efficiency
The RD450 offers the following energy-efficiency features to save energy, reduce operational costs,
increase energy availability, and contribute to the green environment:
Energy-efficient planar components help lower operational costs.
High-efficiency power supplies with 80 PLUS Platinum and Titanium certifications.
Intel Intelligent Power Capability powers individual processor elements on and off as needed, to
reduce power draw.
Low-voltage Intel Xeon processors draw less energy to satisfy the demands of power and thermally
constrained data centers and telecommunication environments.
Low-voltage 1.2 V DDR4 memory DIMMs consume up to 20% less energy compared to 1.35 V
DDR3 DIMMs (even less than 1.5 V DDR3).
Solid-state drives (SSDs) consume less power than traditional spinning HDDs.
Lenovo XClarity Energy Manager provides advanced data center power notification and
management to help achieve lower heat output and reduced cooling needs.
Lenovo ThinkServer RD450 (E5-2600 v4) 3

Other manuals for Lenovo ThinkServer RD450

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lenovo ThinkServer RD450 and is the answer not in the manual?

Lenovo ThinkServer RD450 Specifications

General IconGeneral
Tcase70.9 °C
Bus typeQPI
SteppingM1
FSB ParityNo
Scalability2S
Processor cache15 MB
Processor cores6
Processor modelE5-2609V3
System bus rate6.4 GT/s
Processor seriesIntel Xeon E5-2600 v3
Processor socketLGA 2011-v3
Processor codenameHaswell
Processor frequency1.9 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor package size52.5 x 45 mm
Processor front side bus- MHz
Processor operating modes64-bit
PCI Express configurationsx4, x8, x16
Supported instruction setsAVX 2.0
Thermal Design Power (TDP)85 W
Compatible processor seriesIntel® Xeon®
Number of processors installed1
Maximum number of SMP processors2
Maximum number of PCI Express lanes40
Memory types supported by processorDDR4-SDRAM
Memory channels supported by processorQuad
Memory clock speeds supported by processor1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)51 GB/s
Maximum internal memory supported by processor768 GB
Intelligent Platform Management Interface (IPMI) supportYes
HDD size- \
RAID levels0, 1, 10
HDD interface-
Optical drive typeDVD±RW
Supported HDD sizes2.5 \
Total storage capacity0 GB
Maximum storage capacity28.8 TB
Number of HDDs installed0
Number of HDDs supported8
Supported storage drive interfacesSAS, Serial ATA
Memory slots16
Internal memory8 GB
Memory clock speed2133 MHz
Maximum internal memory512 GB
Memory layout (slots x size)1 x 8 GB
Graphics cardAST2400
Security featuresPower-on & administrator password
Graphics card familyAspeed
Cabling technology10/100/1000Base-T(X)
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports3
PCI Express slots version3.0
Compatible operating systemsMicrosoft Windows Server 2012 R2, 2012, and 2008 R2, Windows Small\\r Business Server 2011, Windows Server Storage 2012 R2 and 2012, Windows\\r Multipoint Server 2012. Red Hat Enterprise Linux 7.0 and 6.5. SUSE Linux\\r Enterprise Server 11 SP3. VMware vSphere (ESXi) 5.1 P5 and 5.5 U2
BIOS typeUEFI
Chassis typeRack (2U)
Power supply550 W
Certification80 PLUS Platinum
Operating altitude0 - 3048 m
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)10 - 35 °C
Operating relative humidity (H-H)8 - 90 %
Processor ARK ID81897
Intel Secure Key Technology version1.00
Intel Identity Protection Technology version0.00
Weight and Dimensions IconWeight and Dimensions
Depth764 mm
Width482 mm
Height87 mm
