Lenovo ThinkServer RD450 Product Guide

PCI
Expansion
slots
Up to six slots, depending on the riser cards installed. The slots are numbered as follows
(see the rear view in Locations of key components and connectors for slot locations). With
one CPU, three slots are available with two riser cards (slots 1, 2, and 5).
1. PCIe 3.0 x8 (x16 mechanical) FHHL slot (riser 1)
2. PCIe 3.0 x8 (x16 mechanical) FHHL slot (riser 1)
3. PCIe 3.0 x8 (x16 mechanical) Low Profile slot (riser 2, requires CPU 2)
4. PCIe 3.0 x8 (x16 mechanical) Low Profile slot (riser 2, requires CPU 2)
5. PCIe 3.0 x8 (x16 mechanical) Low Profile slot (riser 2)
6. PCIe 3.0 x8 (x16 mechanical) Low Profile slot (requires CPU 2)
Ports Front: 2x USB 2.0 and 1x VGA port.
Rear: 2x USB 3.0, 1x DB-15 VGA video, 1x RJ-45 systems management, 2x RJ-45 GbE
network ports, 1x DB-9 serial port
Internal: 2x SD Card slots (supporting SDHC cards; for embedded hypervisor)
Cooling Up to 4 simple-swap (non-hot-swap) redundant fans:
With 1 processor: 3 fans (2 + 1 redundant)
With 2 processors: 4 fans (3 + 1 redundant)
Power supply Up to two redundant hot-swap AC power supplies, Energy Start 2.0 compliant:
450W 80 PLUS Gold (110-240V AC) (machine types 70DA, 70DC only)
550 W 80 PLUS Platinum (110-240V AC)
750 W 80 PLUS Platinum AC (110-240V AC)
750 W 80 PLUS Titanium AC (220-240V AC)
1100 W 80 PLUS Platinum AC (110-240V AC)
Hot-swap
parts
Hard drives and power supplies
Systems
management
UEFI, ThinkServer System Management (TSM) based on ASPEED AST2400, IPMI 2.0-compliant
baseboard management controller (BMC), Support for Lenovo XClarity Administrator. Optional
TSM Premium Upgrade software feature for remote presence. ThinkServer Deployment Manager.
Lenovo XClarity Energy Manager (activated with TSM Premium or separate license).
Security
features
Power-on and administrator password. Optional Trusted Platform Module (TCG 1.2-compliant).
Chassis intrusion switch standard on some models, not available on others.
Video Onboard Aspeed AST2400 with 16MB memory, one DisplayPort on front, one VGA on rear.
Maximum resolution: 1920x1200@60Hz
Operating
systems
supported
Microsoft Windows Server 2012 R2, 2012, and 2008 R2, Red Hat Enterprise Linux 6 and 7, SUSE
Linux Enterprise Server 11, VMware vSphere (ESXi) 5.1, 5.5 and 6.0 (ESXi does not support the
RAID 110i or AnyRAID 110i controllers)
Limited
warranty
One- or three-year limited onsite service with 9x5/Next Business Day
Service and
support
Optional service upgrades are available through Lenovo Services
Dimensions Height: 87 mm (3.4 in), width: 482 mm (19 in), depth: 783 mm (30.8 in)
Weight Minimum configuration: 16 kg (35.3 lb), maximum: 27 kg (59.5 lb)
Components Specification
Models
Lenovo ThinkServer RD450 (E5-2600 v4) 7

Lenovo ThinkServer RD450 Specifications

General

Tcase	70.9 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	15 MB
Processor cores	6
Processor model	E5-2609V3
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor codename	Haswell
Processor frequency	1.9 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	85 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	51 GB/s
Maximum internal memory supported by processor	768 GB
Intelligent Platform Management Interface (IPMI) support	Yes
HDD size	- \
RAID levels	0, 1, 10
HDD interface	-
Optical drive type	DVD±RW
Supported HDD sizes	2.5 \
Total storage capacity	0 GB
Maximum storage capacity	28.8 TB
Number of HDDs installed	0
Number of HDDs supported	8
Supported storage drive interfaces	SAS, Serial ATA
Memory slots	16
Internal memory	8 GB
Memory clock speed	2133 MHz
Maximum internal memory	512 GB
Memory layout (slots x size)	1 x 8 GB
Graphics card	AST2400
Security features	Power-on & administrator password
Graphics card family	Aspeed
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
PCI Express slots version	3.0
Compatible operating systems	Microsoft Windows Server 2012 R2, 2012, and 2008 R2, Windows Small\\r Business Server 2011, Windows Server Storage 2012 R2 and 2012, Windows\\r Multipoint Server 2012. Red Hat Enterprise Linux 7.0 and 6.5. SUSE Linux\\r Enterprise Server 11 SP3. VMware vSphere (ESXi) 5.1 P5 and 5.5 U2
BIOS type	UEFI
Chassis type	Rack (2U)
Power supply	550 W
Certification	80 PLUS Platinum
Operating altitude	0 - 3048 m
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	8 - 90 %
Processor ARK ID	81897
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Depth	764 mm
Width	482 mm
Height	87 mm
