Lenovo ThinkServer RD450 Product Guide

Memory
protection
ECC, Patrol Scrubbing, Demand Scrubbing, Sparing, Mirroring, and Lockstep Mode
Disk drive
bays
Up to 24x 2.5" hot-swap SAS/SATA HDDs/SSDs, or
Up to 8x 3.5" hot-swap SAS/SATA HDDs/SSDs, or
Up to 8x 2.5" easy-swap SAS/SATA HDDs
Maximum
internal
storage
With 3.5-inch hot-swap drives, up to 64 TB with 8x 8 TB NL SATA drives or 12.8 TB with 8x 1.6 TB
SSDs. With 3.5-inch easy-swap drives, up to 48 TB with 8x 6 TB NL SAS drives. With 2.5-inch
drives, up to 48 TB with 24x 2 TB SATA drives or 43.2 TB with 24x 1.8 TB SSDs. Intermix of
SAS/SATA is supported.
Storage
controllers
for 2.5-inch
drive bay
models
Models with 2.5-inch drives support an AnyRAID adapter installed on a dedicated slot on
the drive backplane. Supported controllers are as follows:
AnyRAID 110i 6 Gb SATA RAID 0/1/10 with optional RAID 5. This is a pass-through card
that routes the embedded controller in the Intel C610 PCH to the backplane. Maximum 6
SATA drives.
AnyRAID 510i 6 Gb SAS & SATA RAID 0/1/10 with optional RAID 5/50. Maximum 8 drives.
AnyRAID 720i 12Gb RAID 0/1/5/6/10/50/60 with optional 1 GB cache (without flash), or 1
GB, 2 GB or 4 GB cache each with CacheVault (flash), CacheCade, and FastPath support.
Maximum 8 drives.
AnyRAID 720ix 12 Gb RAID 0/1/5/6/10/50/60 with optional 1 GB cache (without flash), or 1
GB, 2GB or 4GB cache each with CacheVault (flash), CacheCade, and FastPath support.
Includes SAS Expander to support up to 24 drives.
Models with 2.5-inch drives also support PCIe RAID adapter installed in slot 1:
RAID 520i PCIe 12 Gb SAS & SATA RAID 0/1/10 with optional RAID 5/50.
RAID 720i PCIe 12Gb RAID 0/1/5/6/10/50/60 with optional 1 GB cache (without flash), or 1
GB, 2 GB or 4 GB cache each with CacheVault (flash), CacheCade, and FastPath support.
Storage
controllers
for 3.5-inch
drive bay
models
Models with 3.5-inch drives support either an embedded controller or a PCIe RAID
adapter. Supported controllers are as follows:
Embedded RAID 110i 6 Gb controller in the Intel C610 PCH routed via cable to the
backplane. SATA drives only. RAID arrays can include at most six drives.
RAID 520i PCIe 12 Gb SAS & SATA RAID 0/1/10 with optional RAID 5/50.
RAID 720i PCIe 12Gb RAID 0/1/5/6/10/50/60 with optional 1 GB cache (without flash), or 1
GB, 2 GB or 4 GB cache each with CacheVault (flash), CacheCade, and FastPath support.
Optical drive
bays
One optional slimline drive, either a DVD-ROM or Multiburner, is supported with these
configurations:
8x 3.5-inch drive bays
8x 2.5-inch drive bays
16x 2.5-inch drive bays
Tape drive
bays
Support for an LTO6 internal tape drive in configurations with 8x 2.5-inch drive bays.
Network
interfaces
Two integrated RJ-45 Gigabit Ethernet 1000BASE-T ports (Intel i210) for the operating system,
Port 1 can be configured as shared with with systems management. Dedicated Gigabit Ethernet
port for systems management
Components Specification
Lenovo ThinkServer RD450 (E5-2600 v4) 6

Lenovo ThinkServer RD450 Specifications

General

Tcase	70.9 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	15 MB
Processor cores	6
Processor model	E5-2609V3
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor codename	Haswell
Processor frequency	1.9 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	85 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	51 GB/s
Maximum internal memory supported by processor	768 GB
Intelligent Platform Management Interface (IPMI) support	Yes
HDD size	- \
RAID levels	0, 1, 10
HDD interface	-
Optical drive type	DVD±RW
Supported HDD sizes	2.5 \
Total storage capacity	0 GB
Maximum storage capacity	28.8 TB
Number of HDDs installed	0
Number of HDDs supported	8
Supported storage drive interfaces	SAS, Serial ATA
Memory slots	16
Internal memory	8 GB
Memory clock speed	2133 MHz
Maximum internal memory	512 GB
Memory layout (slots x size)	1 x 8 GB
Graphics card	AST2400
Security features	Power-on & administrator password
Graphics card family	Aspeed
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
PCI Express slots version	3.0
Compatible operating systems	Microsoft Windows Server 2012 R2, 2012, and 2008 R2, Windows Small\\r Business Server 2011, Windows Server Storage 2012 R2 and 2012, Windows\\r Multipoint Server 2012. Red Hat Enterprise Linux 7.0 and 6.5. SUSE Linux\\r Enterprise Server 11 SP3. VMware vSphere (ESXi) 5.1 P5 and 5.5 U2
BIOS type	UEFI
Chassis type	Rack (2U)
Power supply	550 W
Certification	80 PLUS Platinum
Operating altitude	0 - 3048 m
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	8 - 90 %
Processor ARK ID	81897
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Depth	764 mm
Width	482 mm
Height	87 mm
