Disk drive
bays
Internal drive bay options (mutually exclusive):
8x, 16x or 32x 2.5-inch hot-swap drive bays
5x or 15x 3.5-inch hot-swap drive bays
5x 3.5-inch easy-swap drive bays
Two M.2 SSDs and an optional M.2 storage module with a dedicated connector. Two SDHC
Cards and an optional SD module installed with a dedicated connector.
Maximum
internal
storage
120 TB with 15x 8 TB 3.5-inch NL SAS HDDs or 64 TB with 32x 2 TB 2.5-inch NL SATA HDDs. Intermix
of SAS/SATA is supported.
Storage
controller
Supports an AnyRAID adapter installed in a dedicated slot on the drive backplane or a PCIe
RAID adapter installed in a standard PCIe slot:
AnyRAID 110i 6 GB SATA RAID 0/1/10 with optional RAID 5. This is a pass-through card that
routes the embedded controller in the Intel C610 PCH to the backplane. Maximum 6 SATA
drives.
AnyRAID 510i 6 GB SAS & SATA RAID 0/1/10 with optional RAID 5/50. Maximum 8 drives.
AnyRAID 720i 12Gb RAID 0/1/5/6/10/50/60 with optional 1 GB cache (without flash), or 1 GB, 2
GB or 4 GB cache each with CacheVault (flash), CacheCade, and FastPath support. Maximum 8
drives.
AnyRAID 720ix 12 GB RAID 0/1/5/6/10/50/60 with optional 1 GB cache (without flash), or 1 GB,
2GB or 4GB cache each with CacheVault (flash), CacheCade, and FastPath support. Includes
SAS Expander to support up to 16 drives.
2x AnyRAID 720ix controllers for support of 32 drives (also requires a PCIe Expander Card to be
installed in PCIe Slot 3).
RAID 520i PCIe 12 GB SAS & SATA RAID 0/1/10 with optional RAID 5/50. Maximum 8 drives.
RAID 720i PCIe 12Gb RAID 0/1/5/6/10/50/60 with optional 1 GB cache (without flash), or 1 GB, 2
GB or 4 GB cache each with CacheVault (flash), CacheCade, and FastPath support. Maximum 8
drives.
Optical drive
bays
One or two optional slimline drives, one standard in some models. Support for DVD-ROM or Multiburner.
Tape drive
bays
One optional LTO6 tape drive. Requires AnyRAID 720ix controller.
Network
interfaces
Two integrated RJ-45 Gigabit Ethernet 1000BASE-T ports (Intel i210) for the operating system. Port 1
can be configured as shared with with systems management. Dedicated Gigabit Ethernet port for
systems management.
PCI
Expansion
slots
Up to seven slots, depending on the number of processors installed. The slots are numbered as follows
(see the rear view in Locations of key components and connectors for slot locations):
1. PCIe 3.0 x16 FH/FL (supports double-width cards)
2. PCIe 3.0 x8 (x16 mechanical) FH/FL
3. PCIe 3.0 x8 (x16 mechanical) FH/FL
4. PCIe 3.0 x8 (x16 mechanical) FH/FL (requires CPU 2)
5. PCIe 3.0 x16 FH/FL (requires CPU 2)
6. PCIe 3.0 x8 (x16 mechanical) FH/FL (requires CPU 2)
7. PCIe 3.0 x8 (x16 mechanical) FH/FL (requires CPU 2)
